2N6768 Series

Catalog

MOSFET N-CH 400V 14A TO254AA

Part	Drive Voltage (Max Rds On, Min Rds On)	Package / Case	Gate Charge (Qg) (Max) @ Vgs	Current - Continuous Drain (Id) @ 25°C	Technology	Mounting Type	Vgs (Max)	FET Type	Vgs(th) (Max) @ Id	Rds On (Max) @ Id, Vgs	Drain to Source Voltage (Vdss)	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Power Dissipation (Max)
Microsemi Corporation 2N6768T1	10 V	TO-254-3 TO-254AA	110 nC	14 A	MOSFET (Metal Oxide)	Through Hole	20 V	N-Channel	4 V	400 mOhm	400 V	TO-254AA	150 °C	-55 °C	4 W 150 W
Microsemi Corporation 2N6768	10 V	TO-204AE	110 nC	14 A	MOSFET (Metal Oxide)	Through Hole	20 V	N-Channel	4 V	400 mOhm	400 V	TO-3	150 °C	-55 °C	4 W 150 W
