2367449 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
11P,RAST 2.5 TAB HEADER,EX- LOCK
| Part | Connector Type | Fastening Type | Material Flammability Rating | Pitch - Mating | Pitch - Mating | Contact Length - Post | Contact Length - Post | Contact Finish - Post | Row Spacing - Mating | Row Spacing - Mating | Voltage Rating | Insulation Material | Shrouding | Features | Current Rating (Amps) | Insulation Color | Termination | Number of Positions Loaded | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Number of Positions | Contact Shape | Number of Rows | Insulation Height | Insulation Height | Mounting Type | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Header | Locking Ramp | UL94 V-0 | 2.5 mm | 0.098 in | 0.114 in | 2.9 mm | Tin | 0.148 in | 3.75 mm | 250 VAC | Polyamide (PA66) Nylon 6/6 | Shrouded - 4 Wall | Board Guide Glow Wire Compliant | 2 A | Natural | Solder | All | Copper Alloy | -40 °C | 120 °C | Tab | 11 | Rectangular | 2 | 15.5 mm | 0.61 in | Through Hole | Board to Cable/Wire |
