3310P Series
Manufacturer: Bourns Inc.
Beta
⌘K
POT 100K OHM 1/4W PLASTIC LINEAR
| Part | Rotation | Mounting Type | Termination Style | Built in Switch | Power (Watts) | Power (Watts) | Resistive Material | Features | Number of Turns | Taper | Actuator Type | Number of Gangs | Actuator Length [x] | Actuator Length [x] | Resistance (Ohms) | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Size - Body [y] | Size - Body [x] | Size - Body [x] | Size - Body [y] | Temperature Coefficient | Bushing Thread | Adjustment Type | Tolerance | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 300 ░ | Panel Mount | PC Pins | None | 0.25 W | 0.25 W | Conductive Plastic | Sealed | 1 | Linear | Flatted | 1 | 12.7 mm | 0.5 in | 100k | 3.18 mm | 0.125 in | 0.375 " | 9.53 mm | 0.375 " | 9.53 mm | 1000 ppm/°C | 1/4-32 | Top Adjustment | 20 % | |
 Bourns Inc. | 300 ░ | Through Hole | PC Pins | None | 0.25 W | 0.25 W | Conductive Plastic | Sealed | 1 | Linear | Slotted | 1 | 5.59 mm | 0.22 in | 100k | 3.18 mm | 0.125 in | 0.375 " | 9.53 mm | 0.375 " | 9.53 mm | 1000 ppm/°C | Top Adjustment | 20 % | ||
Bourns Inc. | 300 ░ | Panel Mount | PC Pins | None | 0.25 W | 0.25 W | Conductive Plastic | Sealed | 1 | Linear | Flatted | 1 | 12.7 mm | 0.5 in | 10k | 3.18 mm | 0.125 in | 0.375 " | 9.53 mm | 0.375 " | 9.53 mm | 1000 ppm/°C | 1/4-32 | Top Adjustment | 20 % | |
 Bourns Inc. | 300 ░ | Panel Mount | PC Pins | None | 0.25 W | 0.25 W | Conductive Plastic | Sealed | 1 | Linear | Slotted | 1 | 12.7 mm | 0.5 in | 100k | 3.18 mm | 0.125 in | 0.375 " | 9.53 mm | 0.375 " | 9.53 mm | 1000 ppm/°C | 1/4-32 | Top Adjustment | 20 % | |
 Bourns Inc. | 300 ░ | Panel Mount | PC Pins | None | 0.25 W | 0.25 W | Conductive Plastic | Sealed | 1 | Linear | Slotted | 1 | 12.7 mm | 0.5 in | 3.18 mm | 0.125 in | 0.375 " | 9.53 mm | 0.375 " | 9.53 mm | 1000 ppm/°C | 1/4-32 | Top Adjustment | 20 % | 20 kOhms |
