Schaffner RR-Series Series

Catalog

S IND CM CHOKES

Part	Height (Max) [z]	Height (Max) [z]	Filter Type	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Package / Case	Mounting Type	Inductance @ Frequency	Height (Max) [z]	Height (Max) [Max] [z]	Height (Max) [Max] [z]
TE Connectivity AMP Connectors RR1000-60	7.165 in	182 mm	Power Line	-40 C	100 °C	1.22 in	240 mm	9.449 in	31 mm	Nonstandard	Chassis Mount	17 µH
TE Connectivity AMP Connectors RR1000-20			Power Line	-40 C	100 °C	1.181 in	115 mm	4.528 in	30 mm	Nonstandard	Chassis Mount	39 µH
TE Connectivity AMP Connectors RR1000-30		4.803 in	Power Line	-40 C	100 °C	1.22 in	170 mm	6.693 "	31 mm	Nonstandard	Chassis Mount	25 µH	122 mm
TE Connectivity AMP Connectors RR1000-10	3.071 in	78 mm	Power Line	-40 C	100 °C	1.181 in	98 mm	3.858 "	30 mm	Nonstandard	Chassis Mount	19 µH
TE Connectivity AMP Connectors RR1000-40	5.551 in	141 mm	Power Line	-40 C	100 °C	1.417 "	180 mm	7.087 in	36 mm	Nonstandard	Chassis Mount	35 µH
TE Connectivity AMP Connectors RR1000-50			Power Line	-40 C	100 °C	1.417 "	200 mm	7.874 in	36 mm	Nonstandard	Chassis Mount	27 µH		5.984 in	152 mm
