DA(UL) Series
Manufacturer: Sensata-Crydom
Beta
⌘K
RELAY REED SPST-NC 5KV 5V
| Part | Coil Resistance | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Termination Style | Coil Current | Must Operate Voltage | Contact Form | Coil Voltage | Coil Type | Operate Time | Contact Material | Contact Rating (Current) | Switching Voltage [Max] | Release Time | Must Release Voltage | Switching Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | 38 Ohms | -20 ░C | 70 °C | Through Hole | PC Pin Wire Leads | 132 mA | 3.7 VDC | SPST-NC (1 Form B) | 5 VDC | Non Latching | 2 ms | Rhodium (Rh) | 3 A | 1000 VAC 1000 VDC | 3 ms | 0.5 VDC | |
 Sensata-Crydom | -20 ░C | 70 °C | Through Hole | PC Pin Wire Leads | 179 mA | 3.7 VDC | SPST-NO (1 Form A) | 5 VDC | Non Latching | 3 ms | Rhodium (Rh) | 3 A | 1000 VAC 1000 VDC | 2 ms | 0.5 VDC | ||
 Sensata-Crydom | -20 ░C | 70 °C | Chassis Mount | Quick Connect - 0.250" (6.3mm) | 30.8 mA | 20 VDC | SPST-NO (1 Form A) | 24 VDC | Non Latching | 3 ms | Tungsten (W) | 2 A | 5000 VDC 5000 VAC | 2 ms | 4 VDC | ||
Sensata-Crydom | -20 ░C | 70 °C | Chassis Mount | Quick Connect - 0.250" (6.3mm) | 132 mA | 3.7 VDC | SPST-NC (1 Form B) | 5 VDC | Non Latching | 2 ms | Rhodium (Rh) | 3 A | 1000 VAC 1000 VDC | 3 ms | 0.5 VDC | ||
 Sensata-Crydom | -20 ░C | 70 °C | Through Hole | PC Pin Solder Turret | 50 mA | 9 VDC | SPST-NC (1 Form B) | 12 VDC | Non Latching | 2 ms | Rhodium (Rh) | 3 A | 1000 VAC 1000 VDC | 3 ms | 1.25 VDC | ||
 Sensata-Crydom | 28 Ohms | -20 ░C | 70 °C | Chassis Mount | Solder Turret | 179 mA | 3.7 VDC | SPST-NO (1 Form A) | 5 VDC | Non Latching | 3 ms | Rhodium (Rh) | 3 A | 1000 VAC 1000 VDC | 2 ms | 0.5 VDC | |
 Sensata-Crydom | -20 ░C | 70 °C | Chassis Mount | Quick Connect - 0.250" (6.3mm) | 131.6 mA | 3.7 VDC | SPST-NC (1 Form B) | 5 VDC | Non Latching | 2 ms | Rhodium (Rh) | 3 A | 1000 VAC 1000 VDC | 3 ms | 0.5 VDC | ||
Sensata-Crydom | -20 ░C | 70 °C | Chassis Mount | Quick Connect - 0.250" (6.3mm) | 25.9 mA | 20 VDC | SPST-NC (1 Form B) | 24 VDC | Non Latching | 2 ms | Rhodium (Rh) | 3 A | 1000 VAC 1000 VDC | 3 ms | 4 VDC | ||
 Sensata-Crydom | 150 Ohms | -20 ░C | 70 °C | Through Hole | PC Pin | 80 mA | 9 VDC | SPST-NO (1 Form A) | 12 VDC | Non Latching | 3 ms | Tungsten (W) | 2 A | 2 ms | 1.25 VDC | 3500 VDC 3500 VAC | |
 Sensata-Crydom | -20 ░C | 70 °C | Through Hole | PC Pin Solder Turret | 179 mA | 3.7 VDC | SPST-NO (1 Form A) | 5 VDC | Non Latching | 3 ms | Tungsten (W) | 2 A | 2 ms | 0.5 VDC | 7000 VAC 7000 VDC |
