CP5 Series
Manufacturer: PULS, LP
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
AC/DC DIN RAIL SUPPLY 24V 120W
| Part | Power (Watts) | Operating Temperature (Max) | Operating Temperature (Min) | Current - Output (Max) | Voltage - Output 1 | Features | AC Voltage - Input (Max) | AC Voltage - Input (Min) | Efficiency | Approval Agency | Standard Number | DC Voltage - Input (Min) | Input Type | Number of Outputs | Voltage - Isolation | Applications | Size / Dimension Width | Size / Dimension Height | Size / Dimension Length | DC Voltage - Input (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 PULS, LP | 120 W | 70 °C | -25 °C | 5 A | 24 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 264 VAC | 85 VAC | 93.6 % | ATEX EAC IEC IECEx UL | 61010-2-201 62368-1 Class I Div 2 | 110 V | AC AC or DC DC | 1 | 500 V | Industrial ITE (Commercial) Laboratory | 1.26 in | 4.88 in | 4.02 in | 150 V |
 PULS, LP | 120 W | 70 °C | -25 °C | 5 A | 24 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 264 VAC | 85 VAC | 93.6 % | ATEX IEC IECEx UL | 61010-2-201 62368-1 Class I Div 2 | 110 V | AC AC or DC DC | 1 | 500 V | Industrial ITE (Commercial) Laboratory | 1.26 in | 4.88 in | 4.02 in | 150 V |
 PULS, LP | 120 W | 70 °C | -25 °C | 2.5 A | 48 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 264 VAC | 85 VAC | 92.6 % | CB CE cULus EAC | 110 V | AC AC or DC DC | 1 | 500 V | Industrial ITE (Commercial) Laboratory | 1.26 in | 4.88 in | 4.02 in | 150 V | |
 PULS, LP | 120 W | 70 °C | -25 °C | 10 A | 12 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 264 VAC | 85 VAC | 93.2 % | ATEX EAC IEC IECEx UL | 61010-2-201 62368-1 Class I Div 2 | 110 V | AC AC or DC DC | 1 | 500 V | Industrial ITE (Commercial) Laboratory | 1.26 in | 4.88 in | 4.02 in | 150 V |
 PULS, LP | 120 W | 70 °C | -25 °C | 5 A | 24 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 264 VAC | 85 VAC | 93.6 % | EAC IEC UL | 61010-2-201 62368-1 | 110 V | AC AC or DC DC | 1 | 500 V | Industrial ITE (Commercial) Laboratory | 1.26 in | 4.88 in | 4.02 in | 300 V |
 PULS, LP | 120 W | 70 °C | -25 °C | 5 A | 24 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 264 VAC | 85 VAC | 93.6 % | ATEX IEC IECEx UL | 61010-2-201 62368-1 Class I Div 2 | 110 V | AC AC or DC DC | 1 | 500 V | Industrial ITE (Commercial) Laboratory | 1.26 in | 4.88 in | 4.02 in | 150 V |
 PULS, LP | 120 W | 70 °C | -25 °C | 5 A | 24 V | Adjustable Output IP20 Load Sharing PFC Universal Input | 264 VAC | 85 VAC | 93.6 % | ATEX EAC IEC IECEx UL | 61010-2-201 62368-1 Class I Div 2 | 110 V | AC AC or DC DC | 1 | 500 V | Industrial ITE (Commercial) Laboratory | 1.26 in | 4.88 in | 4.02 in | 150 V |
