956 Series
Manufacturer: HARTING
Beta
⌘K
D-SUB HIGH DENSITY CONNECTORS 78P FEMALE STRT PCB THRU HOLE S4 PLATING
| Part | Contact Finish Thickness | Contact Finish Thickness | Material Flammability Rating | Mounting Type | Flange Feature | Contact Type | Contact Finish | Termination | Connector Style | Number of Positions | Current Rating (Amps) | Connector Type | Shell Material, Finish | Features | Shell Size, Connector Layout | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Contact Form | Dielectric Material | Contact Material | Flange Feature | Backset Spacing | Backset Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING | 30 Áin | 0.76 Ám | UL94 V-0 | Through Hole | Housing/Shell (Unthreaded) | Signal | Gold Gold-Palladium | Solder | D-Sub High Density | 78 | 2 A | Receptacle Female Sockets | Nickel Plated Steel | |||||||||||
 HARTING | UL94 V-0 | Through Hole | Housing/Shell (Unthreaded) | Signal | Solder | D-Sub High Density | 78 | 2 A | Receptacle Female Sockets | Nickel Plated Steel | ||||||||||||||
 HARTING | Panel Mount | Housing/Shell (Unthreaded) | Signal | D-Sub High Density | 78 | Plug for Male Contacts | Grounding Indents | |||||||||||||||||
 HARTING | 30 Áin | 0.76 Ám | UL94 V-0 | Through Hole | Board Side (4-40) | Signal | Gold Gold-Palladium | Solder | D-Sub High Density | 44 | 2 A | Plug Male Pins | Nickel Plated Steel | Board Lock Grounding Indents | 3 | 3 | ||||||||
 HARTING | UL94 V-0 | Right Angle Through Hole | Housing/Shell | Signal | Solder | D-Sub High Density | 44 | 2 A | Receptacle Female Sockets | Nickel Plated Steel | Board Lock | 3 | 3 | 85 °C | -40 C | Stamped | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Copper Alloy | 4-40 | 8.89 mm | 0.35 in | |||
 HARTING | UL94 V-0 | Through Hole | Board Side (4-40) | Signal | Solder | D-Sub High Density | 78 | 2 A | Plug Male Pins | Nickel Plated Steel | Board Lock Grounding Indents | 85 °C | -40 C | Stamped | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Copper Alloy | ||||||||
 HARTING | 30 Áin | 0.76 Ám | UL94 V-0 | Right Angle Through Hole | Housing/Shell | Signal | Gold Gold-Palladium | Solder | D-Sub High Density | 44 | 2 A | Plug Male Pins | Nickel Plated Steel | Board Lock Grounding Indents | 3 | 3 | 85 °C | -40 C | Stamped | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Copper Alloy | 4-40 | 8.89 mm | 0.35 in |
HARTING | 30 Áin | 0.76 Ám | UL94 V-0 | Right Angle Through Hole | Housing/Shell | Signal | Gold Gold-Palladium | Solder | D-Sub High Density | 44 | 2 A | Receptacle Female Sockets | Nickel Plated Steel | Board Lock | 3 | 3 | 85 °C | -40 C | Stamped | Glass Filled Polybutylene Terephthalate (PBT) Polyester | Copper Alloy | 4-40 | 8.89 mm | 0.35 in |
