794634 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER SMD 10POS 3MM

Part	Applications	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Shrouding	Pitch - Mating	Pitch - Mating	Contact Material	Contact Finish - Mating	Number of Positions Loaded	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Connector Type	Row Spacing - Mating	Row Spacing - Mating	Number of Rows [custom]	Style	Insulation Color	Number of Positions	Voltage Rating	Termination	Features	Operating Temperature [Min]	Operating Temperature [Max]	Material Flammability Rating	Current Rating (Amps)	Insulation Material	Mounting Type	Contact Shape	Contact Type	Insulation Height [z]	Insulation Height [z]	Contact Finish - Post	Fastening Type
TE Connectivity AMP Connectors 4-794634-0	General Purpose	2.54 µm	100 µin	Shrouded - 4 Wall	3 mm	0.118 in	Brass	Gold or Gold-Palladium	All	0.38 µm	15 µin	Header	0.118 in	3 mm	2	Board to Cable/Wire	Black	10	250 V	Solder	Board Lock Pick and Place	-40 C	105 ░C	UL94 V-0	Varies by Wire Gauge	Nylon Polyamide (PA)	Surface Mount	Square	Male Pin	9.25 mm	0.364 in	Tin	Locking Ramp
TE Connectivity AMP Connectors 1-794634-0	General Purpose	2.54 µm	100 µin	Shrouded - 4 Wall	3 mm	0.118 in	Brass	Gold Gold or Gold-Palladium	All	0.38 µm	15 µin	Header	0.118 in	3 mm	2	Board to Cable/Wire	Black	10	250 V	Solder	Board Lock Pick and Place	-40 C	105 ░C	UL94 V-0	Varies by Wire Gauge	Nylon Polyamide (PA)	Surface Mount	Square	Male Pin	9.25 mm	0.364 in	Tin-Lead	Locking Ramp
TE Connectivity AMP Connectors 794634-4	General Purpose	2.54 µm	100 µin	Shrouded - 4 Wall	3 mm	0.118 in	Brass	Gold Gold or Gold-Palladium	All	0.38 µm	15 µin	Header	0.118 in	3 mm	2	Board to Cable/Wire	Black	4	250 V	Solder	Board Lock Pick and Place	-40 C	105 ░C	UL94 V-0	Varies by Wire Gauge	Nylon Polyamide (PA)	Surface Mount	Square	Male Pin	9.25 mm	0.364 in	Tin-Lead	Locking Ramp
TE Connectivity AMP Connectors 5-794634-2	General Purpose	2.54 µm	100 µin	Shrouded - 4 Wall	3 mm	0.118 in	Brass	Gold Gold or Gold-Palladium	All	0.38 µm	15 µin	Header	0.118 in	3 mm	2	Board to Cable/Wire	Black	22	250 V	Solder	Board Lock Pick and Place	-40 C	105 ░C	UL94 V-0	Varies by Wire Gauge	Nylon Polyamide (PA)	Surface Mount	Square	Male Pin	9.25 mm	0.364 in	Tin	Locking Ramp
TE Connectivity AMP Connectors 5-794634-0	General Purpose	2.54 µm	100 µin	Shrouded - 4 Wall	3 mm	0.118 in	Brass	Gold Gold or Gold-Palladium	All	0.38 µm	15 µin	Header	0.118 in	3 mm	2	Board to Cable/Wire	Black	20	250 V	Solder	Board Lock Pick and Place	-40 C	105 ░C	UL94 V-0	Varies by Wire Gauge	Nylon Polyamide (PA)	Surface Mount	Square	Male Pin	9.25 mm	0.364 in	Tin	Locking Ramp
TE Connectivity AMP Connectors 794634-2	General Purpose	2.54 µm	100 µin	Shrouded - 4 Wall			Brass	Gold Gold or Gold-Palladium	All	0.38 µm	15 µin	Header	0.118 in	3 mm	2	Board to Cable/Wire	Black	2	250 V	Solder	Board Lock Pick and Place	-40 C	105 ░C	UL94 V-0	Varies by Wire Gauge	Nylon Polyamide (PA)	Surface Mount	Square	Male Pin	9.25 mm	0.364 in	Tin-Lead	Locking Ramp
