LFD2NX-40 Series
Manufacturer: Lattice Semiconductor Corporation
Beta
⌘K
LATTICE CERTUS -NX GENERAL PURPOSE FPGA ON NEXUS PLATFORM (28NM FD-SOI) ROHS COMPLIANT: YES
| Part | Supplier Device Package | Package / Case | Number of Logic Elements/Cells | Total RAM Bits | Operating Temperature [Min] | Operating Temperature [Max] | Number of LABs/CLBs | Voltage - Supply [Max] | Voltage - Supply [Min] | Mounting Type | Number of I/O | For Use With/Related Products | Contents | Utilized IC / Part | Platform |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Lattice Semiconductor Corporation | 196-CABGA (12x12) | 196-LFBGA | 39000 | 1548288 Bits | 0 °C | 85 °C | 9750 | 1.05 V | 0.95 V | Surface Mount | |||||
 Lattice Semiconductor Corporation | 121-CSFBGA (6x6) | 121-VFBGA CSPBGA | 39000 | 1548288 Bits | 0 °C | 85 °C | 9750 | 1.05 V | 0.95 V | Surface Mount | 71 | ||||
 Lattice Semiconductor Corporation | LFD2NX-40 | Board(s) | LFD2NX-40 | Certus-NX FPGA Versa PCIe Card | |||||||||||
Lattice Semiconductor Corporation | 121-CSFBGA (6x6) | 121-VFBGA CSPBGA | 39000 | 1548288 Bits | -40 °C | 100 °C | 9750 | 1.05 V | 0.95 V | Surface Mount | 71 | ||||
Lattice Semiconductor Corporation | 256-CABGA (14x14) | 256-LFBGA | 39000 | 1548288 Bits | -40 °C | 100 °C | 9750 | 1.05 V | 0.95 V | Surface Mount | 192 | ||||
Lattice Semiconductor Corporation | 121-CSFBGA (6x6) | 121-VFBGA CSPBGA | 39000 | 1548288 Bits | 0 °C | 85 °C | 9750 | 1.05 V | 0.95 V | Surface Mount | 71 | ||||
Lattice Semiconductor Corporation | 256-CABGA (14x14) | 256-LFBGA | 39000 | 1548288 Bits | -40 °C | 100 °C | 9750 | 1.05 V | 0.95 V | Surface Mount | 192 | ||||
Lattice Semiconductor Corporation | 121-CSFBGA (6x6) | 121-VFBGA CSPBGA | 39000 | 1548288 Bits | 0 °C | 85 °C | 9750 | 1.05 V | 0.95 V | Surface Mount | 71 | ||||
Lattice Semiconductor Corporation | 121-CSFBGA (6x6) | 121-VFBGA CSPBGA | 39000 | 1548288 Bits | -40 C | 125 °C | 9750 | 1.05 V | 0.95 V | Surface Mount | 71 | ||||
 Lattice Semiconductor Corporation | 196-CABGA (12x12) | 196-LFBGA | 39000 | 1548288 Bits | 0 °C | 85 °C | 9750 | 1.05 V | 0.95 V | Surface Mount |
