PKM461 Series

Catalog

DC DC CONVERTER 12V 600W

Part	Efficiency	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Voltage - Isolation	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Voltage - Output 1	Applications	Mounting Type	Approval Agency	Number of Outputs	Standard Number	Supplier Device Package	Voltage - Input (Min) [Min]	Control Features	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Features	Power (Watts)	Type	Voltage - Output 1 [custom]
Flex Power Modules PKM4613NHPIHS	96.5 %	-40 °C	125 °C	Quarter Brick	2250 VDC	50 A	75 V	12 V	ITE (Commercial)	Through Hole	CB CSA IEC TUV UL	1	62368-1	Quarter Brick	36 V	Active Low Enable	1.45 in	0.54 "	13.8 mm	2.28 "	36.8 mm	57.9 mm	Baseplate Remote On/Off	600 W	Intermediate Bus Converter
Flex Power Modules PKM4613ANHPISP	96.4 %	-40 °C	125 °C	Quarter Brick	2250 VDC	50 A	75 V		ITE (Commercial)	Through Hole	CB CSA IEC TUV UL	1	62368-1	Quarter Brick	36 V	Active Low Enable	1.45 in	0.45 in	11.4 mm	2.28 "	36.8 mm	57.9 mm	Remote On/Off	580 W	Intermediate Bus Converter	11.6 V
Flex Power Modules PKM4613NHPISP	96.5 %	-40 °C	125 °C	Quarter Brick	2250 VDC	50 A	75 V	12 V	ITE (Commercial)	Through Hole	CB CSA IEC TUV UL	1	62368-1	Quarter Brick	36 V	Active Low Enable	1.45 in	0.45 in	11.4 mm	2.28 "	36.8 mm	57.9 mm	Remote On/Off	600 W	Intermediate Bus Converter
Flex Power Modules PKM4613NHPI	96.5 %	-40 °C	125 °C	Quarter Brick	2250 VDC	50 A	75 V	12 V	ITE (Commercial)	Through Hole	CB CSA IEC TUV UL	1	62368-1	Quarter Brick	36 V	Active Low Enable	1.45 in	0.45 in	11.4 mm	2.28 "	36.8 mm	57.9 mm	Remote On/Off	600 W	Intermediate Bus Converter
