RAYCHEM TAT-125 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

TAT-125-1/4-0-SP-CS34568

Part	Color	Material	Type	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Recovered Wall Thickness	Recovered Wall Thickness	Features	Shrink Temperature	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Shelf Life	Operating Temperature [Min]	Operating Temperature [Max]	Length [x]	Length [x]	Length	Length	Length
TE Connectivity AMP Connectors NB46334001	Black	Polyolefin (PO)	Tubing Flexible	6.4 mm	0.252 in	0.76 mm	0.03 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.125 in	3.18 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C
TE Connectivity AMP Connectors ES55952001	Black	Polyolefin (PO)	Tubing Flexible	12.7 mm	0.5 "	0.76 mm	0.03 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.25 in	6.35 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C	4 ft	1.22 m
TE Connectivity AMP Connectors TAT-125-3/8-0-2IN	Black	Polyolefin	Tubing Flexible	9.53 mm	0.375 in	0.74 mm	0.029 in	Adhesive Lined	95 °C	1	2	0.187 in	4.75 mm	18 °C	35 °C	65 °F	95 °F	60 Months	-55 C	110 °C			0.167 ft	2 in	50.8 mm
TE Connectivity AMP Connectors NB46452001	Red	Polyolefin (PO)	Tubing Flexible	9.53 mm	0.375 in	0.74 mm	0.029 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.187 in	4.75 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C	4 ft	1.22 m
TE Connectivity AMP Connectors NB24132001	White	Polyolefin (PO)	Tubing Flexible	6.4 mm	0.252 in	0.76 mm	0.03 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.125 in	3.18 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C	4 ft	1.22 m
TE Connectivity AMP Connectors TAT-125-1/2-0-2IN	Black	Polyolefin (PO)	Tubing Flexible	12.7 mm	0.5 "	0.76 mm	0.03 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.25 in	6.35 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C
TE Connectivity AMP Connectors ES55922001	Black	Polyolefin (PO)	Tubing Flexible	9.53 mm	0.375 in	0.89 mm	0.035 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.75 "	19.05 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C	4 ft	1.22 m
TE Connectivity AMP Connectors NB24092001	Clear	Polyolefin (PO)	Tubing Flexible	12.7 mm	0.5 "	0.9 mm	0.036 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.25 in	6.35 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C	4 ft	1.22 m
TE Connectivity AMP Connectors NB46382001	White	Polyolefin (PO)	Tubing Flexible	25.4 mm	1 in	1.07 mm	0.042 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.5 "	12.7 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C	4 ft	1.22 m
TE Connectivity AMP Connectors NB46352001	Black	Polyolefin (PO)	Tubing Flexible	38.1 mm	1.5 in	1.19 mm	0.047 in	Adhesive Lined Cut-Through Resistant Flame Retardant	95 °C	1	2	0.75 "	19.05 mm	0 °C	35 °C	32 °F	95 °F	60 Months	-55 C	110 °C	4 ft	1.22 m
