XE Series
Manufacturer: ORION FANS
Beta
⌘K
DC FANS DC AXIAL FAN, 40X40X28MM, 24VDC, 28.6CFM, 9.4W, HIGH PERFORMANCE, BALL, WIRE
| Part | Current Rating (Amps) | Voltage Range [Max] | Voltage Range [Min] | Air Flow | Air Flow | Lifetime @ Temp. | Material - Blade | Power (Watts) | Static Pressure | Static Pressure | Features | Noise | Voltage - Rated | RPM | Operating Temperature | Operating Temperature [Min] | Operating Temperature [Max] | Width [x] | Fan Type | Termination | Size / Dimension [x] | Size / Dimension [z] | Approval Agency | Bearing Type | Width [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ORION FANS | 390 mA | 26 VDC | 14 VDC | 0.801 m³/min | 28.6 CFM | 70000 Hrs | Polybutylene Terephthalate (PBT) | 9.4 W | 2.8 in H2O | 697.4 Pa | Auto Restart | 62.1 dB(A) | 24 VDC | 20900 RPM | (-20 ~ 65°C) | -20 ░C | 65 °C | 28 mm | Tubeaxial | 2 Wire Leads | 40 mm | 40 mm | CE cURus TUV UR | Ball | |
 ORION FANS | 1.8 A | 13.8 VDC | 8 V | 2.93 m³/min | 104.6 CFM | 70000 Hrs | Polybutylene Terephthalate (PBT) | 20.5 W | 1.6 in H2O | 398.6 Pa | Auto Restart | 65.2 dB(A) | 12 VDC | 9450 RPM | (-20 ~ 65°C) | -20 ░C | 65 °C | Tubeaxial | 2 Wire Leads | 80 mm | 80 mm | CE cURus TUV UR | Ball | 25 mm | |
 ORION FANS | 3.7 m³/min | 132 CFM | 60 W | 3.4 in H2O | 846.9 Pa | Auto Restart PWM Control Speed Sensor (Tach) | 73 dB(A) | 24 VDC | 13250 RPM | -10 °C | 70 °C | Tubeaxial | 4 Wire Leads | 80 mm | 80 mm | CE cURus TUV UR | Ball | 38 mm | |||||||
 ORION FANS | 1.37 m³/min | 49 CFM | 7.2 W | 0.78 in H2O | 194.3 Pa | Auto Restart | 63.1 dB(A) | 24 VDC | 7515 RPM | (-20 ~ 65°C) | -20 ░C | 65 °C | Tubeaxial | 2 Wire Leads | 60 mm | 60 mm | CE cURus TUV UR | Ball | 25 mm | ||||||
 ORION FANS | 3.79 m³/min | 133.8 CFM | 21 W | 0.75 in H2O | 186.8 Pa | Auto Restart Speed Sensor (Tach) | 55.2 dB(A) | 24 VDC | 4950 RPM | (-20 ~ 65°C) | -20 ░C | 65 °C | Tubeaxial | 3 Wire Leads | 120 mm | 120 mm | CE cURus TUV UR | Ball | 25 mm |
