MUSBB Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN RCP USB2.0 MINI B 5P PCB
| Part | Insulation Color | Shell/Shielding Material | Contact Finish | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Ingress Protection | Connector Type | Shielding | Number of Contacts | Mounting Feature | Number of Ports | Gender | Mating Cycles | Mounting Type | Termination | Specifications | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Vertical | 1 | Receptacle | 5000 | Panel Mount Through Hole | Solder | USB 2.0 | |
 Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Horizontal | 1 | Receptacle | 5000 | Panel Mount Right Angle Through Hole | Solder | USB 2.0 | Cover |
 Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Horizontal | 1 | Receptacle | 5000 | Panel Mount Right Angle Through Hole | Solder | USB 2.0 | |
 Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Vertical | 1 | Receptacle | 5000 | Panel Mount Through Hole | Solder | USB 2.0 | |
Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Horizontal | 1 | Receptacle | 5000 | Panel Mount Right Angle Through Hole | Solder | USB 2.0 | Cover |
Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Horizontal | 1 | Receptacle | 5000 | Panel Mount Right Angle Through Hole | Solder | USB 2.0 | Cover |
Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Vertical | 1 | Receptacle | 5000 | Panel Mount Through Hole | Solder | USB 2.0 | Cover |
Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Vertical | 1 | Receptacle | 5000 | Panel Mount Through Hole | Solder | USB 2.0 | Cover |
 Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Horizontal | 1 | Receptacle | 5000 | Panel Mount | PC Board Solder | USB 2.0 | Cover |
Amphenol ICC (Commercial Products) | Black | Copper Alloy | Gold | UL94 V-0 | -40 C | 105 ░C | IP67 - Dust Tight Waterproof | USB - mini B | Shielded | 5 | Flange Horizontal | 1 | Receptacle | 5000 | Panel Mount Right Angle Through Hole | Solder | USB 2.0 |
