845-032 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 32POS 0.100
...
| Part | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Contact Finish | Termination | Contact Material | Pitch [x] | Pitch [x] | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Rows | Read Out | Gender | Mounting Type | Number of Positions/Bay/Row [custom] | Card Type | Contact Type | Material - Insulation | Termination Rows | Color | Features | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Wire Wrap | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | 2 | Dual | Female | Through Hole | 16 | Non Specified - Dual Edge | Cantilever | Diallyl Phthalate (DAP) | 2 | Green | |||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Solder | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 4-40 Threaded Insert Top Mount Opening | 1 | Single | Female | Through Hole | 32 | Non Specified - Single Edge | Cantilever | Diallyl Phthalate (DAP) | 1 | Green | |||||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Solder | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | M3 Threaded Insert Top Mount Opening | 1 | Single | Female | Through Hole | 32 | Non Specified - Single Edge | Cantilever | Diallyl Phthalate (DAP) | 1 | Green | |||||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Wire Wrap | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | 1 | Single | Female | Through Hole | 32 | Non Specified - Single Edge | Cantilever | Diallyl Phthalate (DAP) | 1 | Green | |||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Solder | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 2 | Dual | Female | Board Edge Straddle Mount | 16 | Non Specified - Dual Edge | Cantilever | Diallyl Phthalate (DAP) | 2 | Green | Card Extender | |||||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Solder | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 2 | Dual | Female | Through Hole | 16 | Non Specified - Dual Edge | Cantilever | Diallyl Phthalate (DAP) | 2 | Green | 3.25 mm | 0.128 in | ||||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Wire Wrap | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 1 | Single | Female | Through Hole | 32 | Non Specified - Single Edge | Cantilever | Diallyl Phthalate (DAP) | 1 | Green | 3.25 mm | 0.128 in | ||||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Wire Wrap | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 3.25 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 1 | Single | Female | Through Hole | 32 | Non Specified - Single Edge | Cantilever | Diallyl Phthalate (DAP) | 1 | Green | |||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Solder | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 4-40 Threaded Insert Top Mount Opening | 1 | Single | Female | Through Hole | 32 | Non Specified - Single Edge | Cantilever | Diallyl Phthalate (DAP) | 1 | Green | |||||
 EDAC Inc. | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Solder | Copper Alloy | 2.54 mm | 0.1 in | 125 °C | -40 °C | 2.95 mm | Floating Bobbin Top Mount Opening | 0.116 in | 2 | Dual | Female | Through Hole | 16 | Non Specified - Dual Edge | Cantilever | Diallyl Phthalate (DAP) | 2 | Green |
