M20-890 Series
Manufacturer: Harwin Inc.
Beta
⌘K
CONN HEADER SMD R/A 13POS 2.54MM
| Part | Contact Type | Number of Positions Loaded | Current Rating (Amps) | Insulation Material | Contact Length - Mating | Contact Length - Mating | Contact Material | Contact Finish - Mating | Style | Fastening Type | Contact Finish Thickness - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Insulation Color | Contact Shape | Number of Positions | Shrouding | Pitch - Mating | Pitch - Mating | Connector Type | Mounting Type | Insulation Height [z] | Insulation Height [z] | Number of Rows | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | 13 | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 |
 Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | 4 | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 |
 Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 | |
Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | 9 | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 |
Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | 16 | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 |
Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 | |
Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | 11 | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 |
Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | 9 | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 |
Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | 10 | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 |
Harwin Inc. | Male Pin | All | 3 A | Nylon 6T Polyamide (PA6T) | 6 mm | 0.236 in | Brass | Gold | Board to Board Cable | Push-Pull | Flash | -40 C | 105 ░C | Solder | Black | Square | 20 | Unshrouded | 0.1 " | 2.54 mm | Header Cuttable | Right Angle Surface Mount | 3.46 mm | 0.136 in | 1 | UL94 V-0 |
