SG73P2E1 Series
Manufacturer: KOA Speer Electronics, Inc.
Beta
⌘K
RES 86.6K OHM 0.5% 1W 1210
| Part | Composition | Power (Watts) | Temperature Coefficient | Ratings | Features | Package / Case | Package / Case | Number of Terminations [custom] | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Tolerance | Operating Temperature [Max] | Operating Temperature [Min] | Resistance | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 0.5 % | 155 C | -55 C | 86.6 kOhms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 5 % | 155 C | -55 C | 5.6 kOhms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 1 % | 155 C | -55 C | 14 Ohms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 1 % | 155 C | -55 C | 2.55 kOhms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 0.5 % | 155 C | -55 C | 412 kOhms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 1 % | 155 C | -55 C | 56 kOhms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 0.5 % | 155 C | -55 C | 301 Ohms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 1 % | 155 C | -55 C | 17.8 Ohms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 1 % | 155 C | -55 C | 102 kOhms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
KOA Speer Electronics, Inc. | Thick Film | 1 W | 200 ppm/°C | AEC-Q200 | Anti-Sulfur Automotive AEC-Q200 Pulse Withstanding | 1210 | 3225 Metric | 2 | 0.7 mm | 0.028 " | 0.5 % | 155 C | -55 C | 6.8 kOhms | 0.102 in | 2.6 mm | 0.126 " | 3.2 mm | 1210 |
