ADP-RPSF Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RP-SMA JACK (MALE PIN) TO N PLUG
| Part | Body Material | Mating Cycles | Body Finish | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Center Contact Material | Conversion Type | Convert To (Adapter End) | Impedance | Frequency - Max [Max] | Adapter Series | Center Gender | Mounting Type | Style | Convert From (Adapter End) | Center Contact Plating | Adapter Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Brass | 500 | Nickel | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Beryllium Copper | Between Series | N Plug Male Pin | 50 Ohms | 11 GHz | RP-SMA to N | Male to Male | Free Hanging (In-Line) | Straight | Male Pin RP-SMA Jack | Gold | Plug to Jack |
