ERJ-xGN Series

Manufacturer: Panasonic Electronic Components

Catalog

SMD CHIP RESISTOR, ERJ SERIES, 56 OHM, ± 1%, 50 MW, 0201 [0603 METRIC], THICK FILM, PRECISION

Part	Power (Watts)	Power (Watts)	Resistance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Temperature Coefficient	Composition	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Package / Case	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Number of Terminations [custom]	Tolerance	Supplier Device Package	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Panasonic Electronic Components ERJ-1GNF56R0C	0.05 W	50 mW	56 Ohms	0.01 in	0.26 mm	200 ppm/°C	Thick Film	0.012 in	0.024 in	0.3 mm	0.6 mm	0603 Metric	0201	-55 C	125 °C	2	1 %	0201
Panasonic Electronic Components ERJ-XGNF1500Y	0.03125 W	30 mW	150 Ohms			200 ppm/°C	Thick Film	0.2 mm	0.4 mm	0.008 in	0.016 in		01005 (0402 Metric)	-55 C	125 °C	2	1 %	01005	0.15 mm	0.006 "
Panasonic Electronic Components ERJ-1GNF1472C	0.05 W	50 mW	14.7 kOhms	0.01 in	0.26 mm	200 ppm/°C	Thick Film	0.012 in	0.024 in	0.3 mm	0.6 mm	0603 Metric	0201	-55 C	125 °C	2	1 %	0201
Panasonic Electronic Components ERJ-1GNF2433C	0.05 W	50 mW	243 kOhms	0.01 in	0.26 mm	200 ppm/°C	Thick Film	0.012 in	0.024 in	0.3 mm	0.6 mm	0603 Metric	0201	-55 C	125 °C	2	1 %	0201
Panasonic Electronic Components ERJ-1GNF7153C	0.05 W	50 mW	715 kOhms	0.01 in	0.26 mm	200 ppm/°C	Thick Film	0.012 in	0.024 in	0.3 mm	0.6 mm	0603 Metric	0201	-55 C	125 °C	2	1 %	0201
Panasonic Electronic Components ERJ-1GNJ184C	0.05 W	50 mW	180 kOhms	0.01 in	0.26 mm	200 ppm/°C	Thick Film	0.012 in	0.024 in	0.3 mm	0.6 mm	0603 Metric	0201	-55 C	125 °C	2	5 %	0201
Panasonic Electronic Components ERJ-1GNF5761C	0.05 W	50 mW	5.76 kOhms	0.01 in	0.26 mm	200 ppm/°C	Thick Film	0.012 in	0.024 in	0.3 mm	0.6 mm	0603 Metric	0201	-55 C	125 °C	2	1 %	0201
Panasonic Electronic Components ERJ-1GNF2210C	0.05 W	50 mW	221 Ohms	0.01 in	0.26 mm	200 ppm/°C	Thick Film	0.012 in	0.024 in	0.3 mm	0.6 mm	0603 Metric	0201	-55 C	125 °C	2	1 %	0201
Panasonic Electronic Components ERJ-1GNF8060C	0.05 W	50 mW	806 Ohms	0.01 in	0.26 mm	200 ppm/°C	Thick Film	0.012 in	0.024 in	0.3 mm	0.6 mm	0603 Metric	0201	-55 C	125 °C	2	1 %	0201
Panasonic Electronic Components ERJ-XGNF1004Y	0.03125 W	30 mW	1 MOhms			200 ppm/°C	Thick Film	0.2 mm	0.4 mm	0.008 in	0.016 in		01005 (0402 Metric)	-55 C	125 °C	2	1 %	01005	0.15 mm	0.006 "
