KF88X Series

Catalog

D-SUB STANDARD CONNECTORS D9 FML HI-PROF MACH FE-W/BD LCK J/S

Part	Shell Material, Finish	Flange Feature	Features	Shell Size, Connector Layout	Shell Size, Connector Layout	Number of Rows [custom]	Mounting Type	Contact Finish	Material Flammability Rating	Connector Style	Contact Finish Thickness	Termination	Connector Type	Current Rating (Amps)	Contact Type	Number of Positions	Color	Contact Material	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]	Voltage Rating	Shell Size, Connector Layout [x]
Kycon, Inc. KF88X-CD-37S-BR	Nickel Plated Steel	Board Side (4-40)	Board Lock	4	DC C	2	Through Hole	Gold	UL94 V-0	D-Sub	Flash	Solder	Receptacle Female Sockets	2 A	Signal	37
Kycon, Inc. KF88X-BC-25P-BR	Nickel Plated Steel	Board Side (4-40)	Board Lock Grounding Indents		B DB	2	Through Hole	Gold	UL94 V-0	D-Sub	Flash	Solder	Plug Male Pins	2 A	Signal	25	Black	Brass	Polybutylene Terephthalate (PBT) Glass Filled	-55 C	105 ░C	30 VDC	3
Kycon, Inc. KF88X-CC-37S-BRJ	Nickel Plated Steel	Board Side (4-40) Mating Side Female Screwlock (4-40)	Board Lock	4	DC C	2	Through Hole	Gold	UL94 V-0	D-Sub	Flash	Solder	Receptacle Female Sockets	2 A	Signal	37
Kycon, Inc. KF88X-AD-15S-BR	Nickel Plated Steel	Board Side (4-40)	Board Lock	2		2	Through Hole	Gold	UL94 V-0	D-Sub	Flash	Solder	Receptacle Female Sockets	2 A	Signal	15
Kycon, Inc. KF88X-BC-25S-BR	Nickel Plated Steel	Board Side (4-40)	Board Lock		B DB	2	Through Hole	Gold	UL94 V-0	D-Sub	Flash	Solder	Receptacle Female Sockets	2 A	Signal	25							3
Kycon, Inc. KF88X-CD-37S-BRJ	Nickel Plated Steel	Board Side (4-40) Mating Side Female Screwlock (4-40)	Board Lock	4	DC C	2	Through Hole	Gold	UL94 V-0	D-Sub	Flash	Solder	Receptacle Female Sockets	2 A	Signal	37
Kycon, Inc. KF88X-AD-15P-BRJ	Nickel Plated Steel	Board Side (4-40) Mating Side Female Screwlock (4-40)	Board Lock Grounding Indents	2		2	Through Hole	Gold	UL94 V-0	D-Sub	Flash	Solder	Plug Male Pins	2 A	Signal	15
