TMB-E8 Series
Manufacturer: Amphenol CDI
Beta
⌘K
1.85(F)STR,EL,SOLDER
| Part | Impedance | Frequency - Max [Max] | Mounting Type | Body Finish | Body Material | Fastening Type | Insertion Loss | Contact Termination | Center Contact Plating | Connector Style | Center Contact Material | Mating Cycles | Connector Type | Voltage Rating | Housing Color | Number of Ports | Shield Termination | Operating Temperature [Min] | Operating Temperature [Max] | Features | Dielectric Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol CDI | 50 Ohms | 65 GHz | Board Edge End Launch | Gold | Brass | Threaded | 0.6 dB | Solder | Gold | 1.85 mm | Beryllium Copper | 500 | Female Socket Jack | 400 V | Gold | 1 | Solder | -65 ░C | 165 °C | ||
 Amphenol CDI | 50 Ohms | 65 GHz | Board Edge End Launch | Stainless Steel | Threaded | 0.2 dB | Compression | Gold | 1.85 mm | Beryllium Copper | 500 | Female Socket Jack | 400 V | Silver | 1 | Screw | -65 ░C | 165 °C | Field Replaceable For Hermetically Sealed Pin | ||
 Amphenol CDI | 50 Ohms | 67 GHz | Board Edge End Launch | White Bronze | Brass | Threaded | 0.49 dB | Solder | 1.85 mm | Beryllium Copper | 500 | Female Socket Jack | 400 V | Silver | 1 | Solder | -55 C | 85 °C | Polytetrafluoroethylene (PTFE) | ||
Amphenol CDI | 50 Ohms | 65 GHz | Board Edge End Launch | Threaded | Compression | 1.85 mm | Beryllium Copper | Female Socket Jack | Silver | 1 | Screw | Field Replaceable For Hermetically Sealed Pin | |||||||||
Amphenol CDI | 50 Ohms | 67 GHz | Board Edge End Launch | Threaded | Solder | 1.85 mm | Beryllium Copper | Female Socket Jack | Silver | 1 | Solder | ||||||||||
Amphenol CDI | 50 Ohms | 65 GHz | Board Edge End Launch | Gold | Brass | Threaded | 0.6 dB | Solder | Gold | 1.85 mm | Beryllium Copper | 500 | Female Socket Jack | 400 V | Gold | 1 | Solder | -65 ░C | 165 °C |
