NC7SZ14 Series

TinyLogic UHS Inverter with Schmitt Trigger Input

Catalog

TinyLogic UHS Inverter with Schmitt Trigger Input

Part	Logic Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Input Logic Level - Low [Min]	Input Logic Level - Low [Max]	Mounting Type	Current - Quiescent (Max) [Max]	Max Propagation Delay @ V, Max CL	Operating Temperature [Max]	Operating Temperature [Min]	Input Logic Level - High [Max]	Input Logic Level - High [Min]	Features	Current - Output High, Low [y]	Current - Output High, Low [x]	Supplier Device Package	Number of Circuits	Number of Inputs	Package / Case	Supplier Device Package	Supplier Device Package	Supplier Device Package
ON Semiconductor NC7SZ14L6X	Inverter	5.5 V	1.65 V	0.2 V	1.2 V	Surface Mount	1 çA	5.9 ns	85 °C	-40 °C	3.6 V	1.4 V	Schmitt Trigger	32 mA	32 mA	6-MicroPak	1	1	6-UFDFN
ON Semiconductor NC7SZ14L6X-L22175	Inverter	5.5 V	1.65 V	0.5 V	1.7 V	Surface Mount	1 çA	5.9 ns	85 °C	-40 °C	3.6 V	1.4 V	Schmitt Trigger Input	32 mA	32 mA	6-MicroPak	1	1	6-UFDFN
ON Semiconductor NC7SZ14P5X-F40
ON Semiconductor NC7SZ14P5X_F065	Inverter	5.5 V	1.65 V	0.2 V	1.2 V	Surface Mount	1 çA	5.9 ns	85 °C	-40 °C	3.6 V	1.4 V	Schmitt Trigger	32 mA	32 mA	SC-70-5	1	1	5-TSSOP SC-70-5 SOT-353
ON Semiconductor NC7SZ14P5X-L22057	Inverter	5.5 V	1.65 V	0.5 V	1.7 V	Surface Mount		5.9 ns	85 °C	-40 °C	3.6 V	1.4 V	Schmitt Trigger Input	32 mA	32 mA		1	1	5-TSSOP SC-70-5 SOT-353	SC-88A	SOT-353	SC-70-5
ON Semiconductor NC7SZ14FHX-L22175	Inverter	5.5 V	1.65 V	0.5 V	1.7 V	Surface Mount	1 çA	5.9 ns	85 °C	-40 °C	3.6 V	1.4 V	Schmitt Trigger Input	32 mA	32 mA	6-UDFN (1x1)	1	1	6-UFDFN
ON Semiconductor NC7SZ14P5X-F080
ON Semiconductor NC7SZ14FHX	Inverter	5.5 V	1.65 V	0.2 V	1.2 V	Surface Mount	1 çA	5.9 ns	85 °C	-40 °C	3.6 V	1.4 V	Schmitt Trigger	32 mA	32 mA	6-MicroPak2™	1	1	6-UFDFN
ON Semiconductor NC7SZ14M5X-L22090	Inverter	5.5 V	1.65 V	0.5 V	1.7 V	Surface Mount	1 çA	5.9 ns	85 °C	-40 °C	3.6 V	1.4 V	Schmitt Trigger Input	32 mA	32 mA	SOT-23-5	1	1	SC-74A SOT-753
ON Semiconductor NC7SZ14P5X-F080

Catalog

TinyLogic UHS Inverter with Schmitt Trigger Input

Key Features

• Ultra-High Speed: tPD3.7ns (Typical) into 50pF at 5V VCC

• High Output Drive: ±24mA at 3V VCC

• Broad VCCOperating Range: 1.65V to 5.5V

• Matches Performance of LCX when Operated at 3.3V VCCCC

• Power Down High Impedance Inputs/Outputs

• Over-Voltage Tolerance Inputs Facilitate 5V to 3V Translation

• Proprietary Noise/EMI Reduction Circuitry

• Ultra-Small MicroPak™ Packages

• Space-Saving SOT23 and SC70 Packages

Description

The NC7SZ14 is a single inverter with Schmitt trigger input from ON Semiconductor's Ultra-High Speed (UHS) series of TinyLogic®. The device is fabricated with advanced CMOS technology to achieve ultra-high speed with high output drive while maintaining low static power dissipation over a very broad VCCoperating range. The device is specified to operate over the 1.65V to 5.5V VCCrange. The inputs and outputs are high-impedance when VCCis 0V. Inputs tolerate voltages up to 6V independent of VCCoperating voltage.
