FRONT-MSTB Series

Catalog

CONN TERMINAL BLOCK F 2 POS 5.08MM SCREW CABLE MOUNT 12A CARDBOARD

Part	Wire Strip Length	Insulation Height [custom]	Insulation Height [custom]	Screw Size	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Torque - Screw [Max]	Current - IEC	Termination Style	Plug Wire Entry	Number of Levels	Positions Per Level	Type	Number of Positions	Contact Mating Finish	Voltage - IEC	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Wire Gauge or Range - mm² [Max]	Wire Gauge or Range - mm² [Min]	Pitch	Pitch	Features	Mounting Type	Color
Phoenix Contact 1763494	10 mm	27.51 mm	1.083 in	M2.5	0.6 Nm	4.4 Lb-In	0.5 Nm	5.3 Lb-In	12 A	Screw - Pressure Clip	180 °	1	2	Plug Female Sockets	2	Tin	250 V	30 AWG	12 AWG	2.5 mm²	0.2 mm²	5.08 mm	0.2 in	Mating Flange Retention Latches (Non-Wire Side)	Free Hanging (In-Line)	Black
