MGW304812 Series
Manufacturer: Cosel USA, Inc.
Beta
⌘K
DC DC CONVERTER +/-12V 24V 30W
| Part | Voltage - Output 2 | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Input (Min) [Min] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Voltage - Output 1 | Power (Watts) | Package / Case | Mounting Type | Features | Voltage - Isolation | Efficiency | Current - Output (Max) | Number of Outputs | Type | Voltage - Input (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cosel USA, Inc. | -12 V | ITE (Commercial) | -40 °C | 85 °C | 36 V | 0.39 " | 50.8 mm | 25.4 mm | 2 in | 1 " | 9.9 mm | 12V 24V | 30 Watts | 6-DIP Module | Through Hole | Bridgeable | 1000 V | 90 % | 1.25 A | 2 | Isolated Module | 76 V |
