1701A Series
Manufacturer: Belden Inc.
Beta
⌘K
CAT5E+ 4PRB U/UTP CMP REEL
| Part | Conductor Material | Voltage | Number of Conductors | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Length | Length | Ratings | Conductor Strand | Wire Gauge | Jacket (Insulation) Material | Cable Type | Features | Jacket Color | Usage | Conductor Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 304.8 m | 1000 ft | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | White | Network | Fluorinated Ethylene-Propylene (FEP) |
 Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 304.8 m | 1000 ft | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Purple | Network | Fluorinated Ethylene-Propylene (FEP) |
 Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 304.8 m | 1000 ft | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Gray | Network | Fluorinated Ethylene-Propylene (FEP) |
 Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 914.4 m | 3000 ' | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Natural | Network | Fluorinated Ethylene-Propylene (FEP) |
Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 914.4 m | 3000 ' | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Blue | Network | Fluorinated Ethylene-Propylene (FEP) |
Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 304.8 m | 1000 ft | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Natural | Network | Fluorinated Ethylene-Propylene (FEP) |
 Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 304.8 m | 1000 ft | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Yellow | Network | Fluorinated Ethylene-Propylene (FEP) |
 Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 304.8 m | 1000 ft | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Red | Network | Fluorinated Ethylene-Propylene (FEP) |
Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 304.8 m | 1000 ft | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Orange | Network | Fluorinated Ethylene-Propylene (FEP) |
 Belden Inc. | Copper Bare | 300 VDC | 8 | 0.195 " | 4.95 mm | 304.8 m | 1000 ft | UL Style CMP | Solid | 24 AWG | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Multi-Pair Cat5e | Rip Cord | Green | Network | Fluorinated Ethylene-Propylene (FEP) |
