CRS1206Q Series
Manufacturer: Bourns Inc.
Beta
⌘K
SMD CHIP RESISTOR, 10 KOHM, ± 1%, 500 MW, 1206 [3216 METRIC], THICK FILM, HIGH POWER, ANTI-SURGE
| Part | Ratings | Supplier Device Package | Features | Temperature Coefficient | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Power (Watts) | Power (Watts) | Composition | Number of Terminations [custom] | Tolerance | Resistance | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | AEC-Q200 | 1206 | Automotive AEC-Q200 Pulse Withstanding | 100 ppm/°C | 0.026 in | 0.65 mm | 0.5 W | 0.5 W | Thick Film | 2 | 1 % | 10000 Ohms | 155 C | -55 C | 1206 (3216 Metric) | 0.063 " | 1.6 mm | 0.122 " | 3.1 mm |
 Bourns Inc. | AEC-Q200 | 1206 | Automotive AEC-Q200 Pulse Withstanding | 100 ppm/°C | 0.026 in | 0.65 mm | 0.5 W | 0.5 W | Thick Film | 2 | 1 % | 300 kOhms | 155 C | -55 C | 1206 (3216 Metric) | 0.063 " | 1.6 mm | 0.122 " | 3.1 mm |
Bourns Inc. | AEC-Q200 | 1206 | Automotive AEC-Q200 Pulse Withstanding | 200 ppm/°C | 0.026 in | 0.65 mm | 0.5 W | 0.5 W | Thick Film | 2 | 5 % | 47 Ohms | 155 C | -55 C | 1206 (3216 Metric) | 0.063 " | 1.6 mm | 0.122 " | 3.1 mm |
Bourns Inc. | AEC-Q200 | 1206 | Automotive AEC-Q200 Pulse Withstanding | 200 ppm/°C | 0.026 in | 0.65 mm | 0.5 W | 0.5 W | Thick Film | 2 | 5 % | 1000 Ohms | 155 C | -55 C | 1206 (3216 Metric) | 0.063 " | 1.6 mm | 0.122 " | 3.1 mm |
