SRN5040TA Series

Catalog

INDUCTOR, AEC-Q200, SEMI-SHLD, 68UH/0.8A

Part	Tolerance	Shielding	Package / Case	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Current Rating (Amps)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Q @ Freq	Material - Core	Ratings	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Inductance Frequency - Test	Type	DC Resistance (DCR)	Inductance	Current - Saturation (Isat)	Frequency - Self Resonant
Bourns Inc. SRN5040TA-680K	10 %	Shielded	Nonstandard	4.1 mm	0.161 in	800 mA	4.95 mm	0.195 "	4.95 mm	0.195 in	15 100 kHz	Ferrite	AEC-Q200	Surface Mount	-55 C	125 °C	100 kHz	Drum Core Wirewound	400 mOhm	68 µH	900 mA	10 MHz
Bourns Inc. SRN5040TA-2R2M	20 %	Shielded	Nonstandard	4.1 mm	0.161 in	3.8 A	4.95 mm	0.195 "	4.95 mm	0.195 in	15 100 kHz	Ferrite	AEC-Q200	Surface Mount	-55 C	125 °C	100 kHz	Drum Core Wirewound	21 mOhm	2.2 µH	5.7 A	62 MHz
Bourns Inc. SRN5040TA-R60M	20 %	Shielded	Nonstandard	4.1 mm	0.161 in	8 A	4.95 mm	0.195 "	4.95 mm	0.195 in	15 100 kHz	Ferrite	AEC-Q200	Surface Mount	-55 C	125 °C	100 kHz	Drum Core Wirewound	8 mOhm	600 nH	11 A	250 MHz
Bourns Inc. SRN5040TA-101K	10 %	Shielded	Nonstandard	4.1 mm	0.161 in	0.72 A	4.95 mm	0.195 "	4.95 mm	0.195 in	15 100 kHz	Ferrite	AEC-Q200	Surface Mount	-55 C	125 °C	100 kHz	Drum Core Wirewound	560 mOhm	100 µH	750 mA	7 MHz
Bourns Inc. SRN5040TA-150M	20 %	Shielded	Nonstandard	4.1 mm	0.161 in	1.8 A	4.95 mm	0.195 "	4.95 mm	0.195 in	15 100 kHz	Ferrite	AEC-Q200	Surface Mount	-55 C	125 °C	100 kHz	Drum Core Wirewound	80 mOhm	15 µH	2 A	22 MHz
Bourns Inc. SRN5040TA-220M	20 %	Shielded	Nonstandard	4.1 mm	0.161 in	1.5 A	4.95 mm	0.195 "	4.95 mm	0.195 in	15 100 kHz	Ferrite	AEC-Q200	Surface Mount	-55 C	125 °C	100 kHz	Drum Core Wirewound	123 mOhm	22 µH	1.62 A	16 MHz
