QH22028 Series
Manufacturer: APEM Inc.
Beta
⌘K
LED PANEL INDICATOR, GREEN, 22MM, 24VDC ROHS COMPLIANT: YES
| Part | Type | Lamp Color | Lens Transparency | Voltage [Max] | Voltage [Min] | Panel Cutout Shape | Termination Style | Panel Cutout Dimensions | Panel Cutout Dimensions | Ratings | Lens Size [diameter] | Ingress Protection | Lens Color | Lens Style | Current [Max] | Current [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 APEM Inc. | LED | Green | Clear | 26.4 V | 12 V | Round | Wire Leads - 7.87" (200.00mm) | 22 mm | 0.866 in | DC | 42 mm | IP67 | Green | Ring with Domed Top | 20 mA | 4.2 mA |
 APEM Inc. | LED | Red | Clear | 26.4 V | 12 V | Round | Wire Leads - 7.87" (200.00mm) | 22 mm | 0.866 in | DC | 42 mm | IP67 | Red | Ring with Domed Top | 20 mA | 4.2 mA |
