r41 Series

Manufacturer: KEMET

Catalog

SAFETY CAPACITOR, METALLIZED PP, RADIAL BOX - 2 PIN, 1500 PF, ± 10%, Y2, THROUGH HOLE

Part	Voltage Rating - DC	Voltage Rating - DC	Capacitance	Applications	Package / Case	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Voltage Rating - AC	Termination	Lead Spacing	Lead Spacing	Mounting Type	Dielectric Material	Height - Seated (Max) [Max] [z]	Height - Seated (Max)	Tolerance	Operating Temperature [Max]	Operating Temperature [Min]	Ratings	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Size / Dimension [y]
KEMET R413D1150JMT0K	1.5 kV	1.5 kV	1500 pF	Automotive EMI RFI Suppression	Radial	4 mm	0.394 in	0.157 "	10 mm	300 V	PC Pins	0.295 in	7.5 mm	Through Hole	Polypropylene (PP) Metallized	0.358 in	9.1 mm	10 %	125 °C	-40 C	AEC-Q200 X1 Y2
KEMET R41BI268050T0K	1.5 kV	1.5 kV	0.068 µF	Automotive EMI RFI Suppression	Radial	11 mm	0.709 in	0.433 in	18 mm	350 V	PC Pins	0.591 in	15 mm	Through Hole	Polypropylene (PP) Metallized		19.1 mm	10 %	125 °C	-40 C	AEC-Q200 X1 Y2	0.752 "
KEMET R41BI222050T1K	1.5 kV	1.5 kV	0.022 µF	Automotive EMI RFI Suppression	Radial	6 mm	0.709 in	0.236 "	18 mm	350 V	PC Pins	0.591 in	15 mm	Through Hole	Polypropylene (PP) Metallized		12.1 mm	10 %	125 °C	-40 C	AEC-Q200 X1 Y2	0.476 "
KEMET R413F133040M1M	1 kV	1 kVDC	0.0033 µF	Automotive EMI RFI Suppression	Radial	4 mm	0.512 "	0.157 "	13 mm	300 V	PC Pins	0.394 in	10 mm	Through Hole	Polypropylene (PP) Metallized	0.358 in	9.1 mm	20 %	110 °C	-40 C	AEC-Q200 X1 Y2
KEMET R41BI233050T1K	1.5 kV	1.5 kV	0.033 çF	Automotive EMI RFI Suppression	Radial	7.5 mm	0.709 in	0.295 in	18 mm	350 V	PC Pins	0.591 in	15 mm	Through Hole	Polypropylene (PP) Metallized			10 %	125 °C	-40 C	AEC-Q200 X1 Y2
KEMET R413D1220JMT0K	1.5 kV	1.5 kV	2200 pF	Automotive EMI RFI Suppression	Radial	5 mm	0.394 in	0.197 "	10 mm	300 V	PC Pins	0.295 in	7.5 mm	Through Hole	Polypropylene (PP) Metallized	0.417 in		10 %	125 °C	-40 C	AEC-Q200 X1 Y2		10.6 mm
KEMET R41BI233050T0K	1.5 kV	1.5 kV	0.033 çF	Automotive EMI RFI Suppression	Radial	8.5 mm	0.709 in	0.335 in	18 mm	350 V	PC Pins	0.591 in	15 mm	Through Hole	Polypropylene (PP) Metallized	0.575 in		10 %	125 °C	-40 C	AEC-Q200 X1 Y2			14.6 mm
KEMET R41BI168050T0K	1.5 kV	1.5 kV	6800 pF	Automotive EMI RFI Suppression	Radial		0.709 in	0.197 "	18 mm	350 V	PC Pins	0.591 in	15 mm	Through Hole	Polypropylene (PP) Metallized			10 %	125 °C	-40 C	AEC-Q200 X1 Y2	0.437 in		11.1 mm	5 mm
KEMET R41BN247050T0K	1.5 kV	1.5 kV		Automotive EMI RFI Suppression	Radial	6 mm	1.043 in	0.236 "	26.5 mm	350 V	PC Pins	0.886 in	22.5 mm	Through Hole	Polypropylene (PP) Metallized			10 %	125 °C	-40 C	AEC-Q200 X1 Y2	0.594 in		15.1 mm
