M4 Series
Manufacturer: 3M Electronic Specialty
Beta
⌘K
CONN RING CIRC 4AWG #10 10PC
| Part | Contact Finish | Width - Outer Edges [x] | Width - Outer Edges | Wire Gauge | Thickness | Thickness | Termination | Contact Material | Length - Overall | Length - Overall | Stud/Tab Size | Mounting Type | Insulation | Terminal Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 3M Electronic Specialty | Tin | 0.68 " | 17.27 mm | 4 AWG | 0.075 in | 1.91 mm | Crimp | Copper ETP | 1.34 in | 34.04 mm | 10 Stud | Free Hanging (In-Line) | Non-Insulated | Circular | Brazed Seam |
 3M Electronic Specialty | 0.68 " | 17.27 mm | 4 AWG | 0.075 in | 1.91 mm | Crimp | 1.34 in | 34.04 mm | 0.25 Stud | Free Hanging (In-Line) | Non-Insulated | Circular | Brazed Seam | ||
 3M Electronic Specialty | Tin | 0.68 " | 17.27 mm | 4 AWG | 0.075 in | 1.91 mm | Crimp | Copper ETP | 1.34 in | 34.04 mm | 0.3125 Stud | Free Hanging (In-Line) | Non-Insulated | Circular | Brazed Seam |
 3M Electronic Specialty | Tin | 0.68 " | 17.27 mm | 4 AWG | 0.075 in | 1.91 mm | Crimp | Copper ETP | 1.34 in | 34.04 mm | 0.375 Stud | Free Hanging (In-Line) | Non-Insulated | Circular | Brazed Seam |
3M Electronic Specialty | 0.68 " | 17.27 mm | 4 AWG | 0.075 in | 1.91 mm | Crimp | 1.34 in | 34.04 mm | 0.3125 Stud | Free Hanging (In-Line) | Non-Insulated | Circular | Brazed Seam | ||
 3M Electronic Specialty | 0.68 " | 17.27 mm | 4 AWG | 0.075 in | 1.91 mm | Crimp | 1.34 in | 34.04 mm | 0.375 Stud | Free Hanging (In-Line) | Non-Insulated | Circular | Brazed Seam | ||
3M Electronic Specialty | Tin | 0.68 " | 17.27 mm | 4 AWG | 0.075 in | 1.91 mm | Crimp | Copper ETP | 1.34 in | 34.04 mm | 0.25 Stud | Free Hanging (In-Line) | Non-Insulated | Circular | Brazed Seam |
