846-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 36POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Read Out | Contact Material | Card Type | Number of Positions | Termination | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Color | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Number of Positions/Bay/Row [custom] | Mounting Type | Termination Rows | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Non Specified - Dual Edge | 36 | Wire Wrap | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | 18 | Through Hole | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | Copper Alloy | Non Specified - Single Edge | 36 | Solder | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | Through Hole | 1 | 1 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 36 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | Copper Alloy | Non Specified - Single Edge | 36 | Solder | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | Through Hole | 1 | 1 | 0.156 " | 3.96 mm | 36 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | Copper Alloy | Non Specified - Single Edge | 36 | Solder | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | Right Angle Through Hole | 1 | 1 | 0.128 " | 3.25 mm | 36 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Non Specified - Dual Edge | 36 | Solder | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | 18 | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Non Specified - Dual Edge | 36 | Wire Wrap | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | 18 | Through Hole | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Non Specified - Dual Edge | 36 | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | 18 | Through Hole | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | Copper Alloy | Non Specified - Single Edge | 36 | Solder | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | Through Hole | 1 | 1 | 36 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | Copper Alloy | Non Specified - Single Edge | 36 | Wire Wrap | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | Through Hole | 1 | 1 | 0.128 " | 3.25 mm | 36 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | Dual | Copper Alloy | Non Specified - Dual Edge | 36 | Wire Wrap | 0.25 Ám | 10 Áin | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Female | 18 | Through Hole | 0.156 " | 3.96 mm |
