6500-7071 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
BNC M STR NA CR
| Part | Mating Cycles | Body Material | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating | Center Contact Plating | Body Finish | Dielectric Material | Cable Group | Cable Group | Frequency - Max [Max] | Mounting Type | Connector Type | Connector Style | Housing Color | Contact Termination | Fastening Type | Center Contact Material | Shield Termination | Number of Ports | Impedance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | 500 | Brass | 85 °C | -40 C | 500 V | Gold | Nickel | Polytetrafluoroethylene (PTFE) | RG-6 | 6 A | 1.5 GHz | Free Hanging (In-Line) | Plug Male Pin | BNC | Silver | Crimp | Bayonet Lock | Beryllium Copper | Crimp | 1 | 75 Ohms |
 Radiall USA, Inc. | 500 | Brass | 165 °C | -65 ░C | Gold | Nickel | Polytetrafluoroethylene (PTFE) | RG-316DS | 4 GHz | Free Hanging (In-Line) | Plug Male Pin | BNC | Silver | Crimp | Bayonet Lock | Crimp | 1 | 50 Ohms |
