DKA30 Series

Catalog

DC DC CONVERTER +/-12V 30W

Part	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Efficiency	Applications	Type	Mounting Type	Features	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Isolation	Voltage - Input (Max) [Max]	Current - Output (Max)	Voltage - Output 2	Voltage - Output 1	Package / Case	Current - Output (Max)	Current - Output (Max)
MEAN WELL USA Inc. DKA30B-12	2	-40 °C	85 °C	2 in	0.83 "	21 mm	2 in	50.8 mm	50.8 mm	83 %	ITE (Commercial)	Isolated Module	Through Hole	OCP Remote On/Off SCP	18 V	30 Watts	1000 V	36 V	1.25 A	-12 V	12 V	8-DIP Module
MEAN WELL USA Inc. DKA30A-15	2	-40 °C	85 °C	2 in	0.83 "	21 mm	2 in	50.8 mm	50.8 mm	80 %	ITE (Commercial)	Isolated Module	Through Hole	OCP Remote On/Off SCP	9 V	30 Watts	1000 V	18 V	1 A	-15 V	15 V	8-DIP Module
MEAN WELL USA Inc. DKA30A-05	2	-40 °C	85 °C	2 in	0.83 "	21 mm	2 in	50.8 mm	50.8 mm	80 %	ITE (Commercial)	Isolated Module	Through Hole	OCP Remote On/Off SCP	9 V	25 W	1000 V	18 V		-5 V	5 V	8-DIP Module	2.5 A	2.5 A
MEAN WELL USA Inc. DKA30B-15	2	-40 °C	85 °C	2 in	0.83 "	21 mm	2 in	50.8 mm	50.8 mm	83 %	ITE (Commercial)	Isolated Module	Through Hole	OCP Remote On/Off SCP	18 V	30 Watts	1000 V	36 V	1 A	-15 V	15 V	8-DIP Module
MEAN WELL USA Inc. DKA30B-05	2	-40 °C	85 °C	2 in	0.83 "	21 mm	2 in	50.8 mm	50.8 mm	80 %	ITE (Commercial)	Isolated Module	Through Hole	OCP Remote On/Off SCP	18 V	25 W	1000 V	36 V		-5 V	5 V	8-DIP Module	2.5 A	2.5 A
MEAN WELL USA Inc. DKA30A-12	2	-40 °C	85 °C	2 in	0.83 "	21 mm	2 in	50.8 mm	50.8 mm	80 %	ITE (Commercial)	Isolated Module	Through Hole	OCP Remote On/Off SCP	9 V	30 Watts	1000 V	18 V	1.25 A	-12 V	12 V	8-DIP Module
MEAN WELL USA Inc. DKA30C-12	2	-40 °C	85 °C	2 in	0.83 "	21 mm	2 in	50.8 mm	50.8 mm	81 %	ITE (Commercial)	Isolated Module	Through Hole	OCP Remote On/Off SCP	36 V	30 Watts	1000 V	72 V	1.25 A	-12 V	12 V	8-DIP Module
MEAN WELL USA Inc. DKA30C-05	2	-40 °C	85 °C	2 in	0.83 "	21 mm	2 in	50.8 mm	50.8 mm	80 %	ITE (Commercial)	Isolated Module	Through Hole	OCP Remote On/Off SCP	36 V	25 W	1000 V	72 V		-5 V	5 V	8-DIP Module	2.5 A	2.5 A
