EAPL4508 Series

Catalog

LED RGB CLEAR SMD R/A

Part	Lens Size [x]	Lens Size [y]	Package / Case	Mounting Type	Millicandela Rating [custom]	Millicandela Rating [custom]	Millicandela Rating [custom]	Lens Color	Lens Transparency	Wavelength - Dominant	Size / Dimension [y]	Size / Dimension [x]	Voltage - Forward (Vf) (Typ)	Wavelength - Peak	Current - Test	Color	Viewing Angle	Configuration	Height (Max) [Max] [z]	Lens Style
Everlight Electronics Co Ltd EAPL4508RGBA0	3.4 mm	0.8 mm	6-SMD No Lead	Right Angle Surface Mount	900 mcd	325 mcd	500 mcd	Colorless	Clear	460 nm 530 nm 624 nm	1.25 mm	4.5 mm	2.15 V 3.2 V	468 nm 518 nm 632 nm	20mA Blue 20mA Green 20mA Red	Blue Green Red	120 °	Independent	0.9 mm	Oval with Flat Top
