845-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 28POS 0.100
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Color | Number of Positions | Contact Material | Card Type | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Mounting Type | Contact Finish | Contact Type | Pitch | Pitch | Number of Rows | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 125 °C | -40 C | 0.25 Ám | 10 Áin | 28 | Green | 28 | Copper Alloy | Non Specified - Single Edge | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Single | Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | 14 | Green | 28 | Copper Alloy | Non Specified - Dual Edge | Female | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Dual | Board Edge Straddle Mount | Gold | Cantilever | 0.1 " | 2.54 mm | 2 | 2 | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | 14 | Green | 28 | Copper Alloy | Non Specified - Dual Edge | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | 14 | Green | 28 | Copper Alloy | Non Specified - Dual Edge | Female | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Right Angle Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 2 | 2 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | 28 | Green | 28 | Copper Alloy | Non Specified - Single Edge | Female | Single | Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 1 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 125 °C | -40 C | 0.25 Ám | 10 Áin | 14 | Green | 28 | Copper Alloy | Non Specified - Dual Edge | Female | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 125 °C | -40 C | 0.25 Ám | 10 Áin | 14 | Green | 28 | Copper Alloy | Non Specified - Dual Edge | Female | 4-40 Threaded Insert Top Mount Opening | Dual | Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 2 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | 14 | Green | 28 | Copper Alloy | Non Specified - Dual Edge | Female | M3 Threaded Insert Top Mount Opening | Dual | Right Angle Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 2 | 2 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | 28 | Green | 28 | Copper Alloy | Non Specified - Single Edge | Female | M3 Threaded Insert Top Mount Opening | Single | Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 125 °C | -40 C | 0.25 Ám | 10 Áin | 14 | Green | 28 | Copper Alloy | Non Specified - Dual Edge | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Right Angle Through Hole | Gold | Cantilever | 0.1 " | 2.54 mm | 2 | 2 |
