SCC LE Series
Manufacturer: KYOCERA AVX
Beta
⌘K
SUPERCAPACITORS / ULTRACAPACITORS 2.7V 850F 35X115MM W ELDABLE PIN LOW ESR
| Part | Tolerance [Max] | Tolerance [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Termination | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Size / Dimension [diameter] | Size / Dimension [diameter] | Lifetime @ Temp. | Voltage - Rated | ESR (Equivalent Series Resistance) | Package / Case | Capacitance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KYOCERA AVX | 30 % 100 % | -10 % 0 % | -40 C | 65 °C | Chassis Mount | Weld Stud | 4.606 " | 117 mm | 1.378 " | 35 mm | 1000 Hrs | 2.7 VDC | 0.8 mOhm | Can Radial | 850 F |
