XCL225 Series

Catalog

DC DC CONVERTER 1-15V

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Features	Voltage - Input (Max) [Max]	Applications	Supplier Device Package	Mounting Type	Type	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output (Max) [Max]	Voltage - Input (Min) [Min]	Voltage - Output 1 [Max]	Voltage - Output 1 [Min]	Number of Outputs
Torex Semiconductor Ltd XCL225A0K1H2	3 mm	3 mm	0.12 inches	0.07 in	1.7 mm	0.12 in	OCP OTP UVLO	18 V	ITE (Commercial)	DFN3030-10B	Surface Mount	Non-Isolated PoL Module	10-PowerLFDFN Module	-40 C	105 ░C	500 mA	3 V	15 V	1 V	1
Torex Semiconductor Ltd XCL225B0K1H2	3 mm	3 mm	0.12 inches	0.07 in	1.7 mm	0.12 in	OCP OTP UVLO	18 V	ITE (Commercial)	DFN3030-10B	Surface Mount	Non-Isolated PoL Module	10-PowerLFDFN Module	-40 C	105 ░C	500 mA	3 V	15 V	1 V	1
