CBS502405 Series

Catalog

DC DC CONVERTER 5V 50W

Part	Number of Outputs	Voltage - Isolation	Features	Voltage - Input (Min) [Min]	Applications	Supplier Device Package	Voltage - Input (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output (Max) [Max]	Power (Watts)	Mounting Type	Package / Case	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Efficiency	Type	Voltage - Output 1
Cosel USA, Inc. CBS502405-RF2	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	26.5 mm	62 mm	2.44 "	2.34 in	1.04 in	59.5 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-F2	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	26.5 mm	62 mm	2.44 "	2.34 in	1.04 in	59.5 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-F5	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	52 mm	62.5 mm	2.46 "	2.31 in	2.05 in	58.7 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-F3	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	39.2 mm	62.5 mm	2.46 "	2.31 in	1.54 in	58.7 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-F1	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	26.5 mm	62.5 mm	2.46 "	2.31 in	1.04 in	58.7 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-F4	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	39.2 mm	62 mm	2.44 "	2.34 in	1.54 in	59.5 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-R	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	12.7 mm	61 mm	2.4 in	2.28 in	0.5 in	57.9 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-T	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	12.7 mm	61 mm	2.4 in	2.28 in	0.5 in	57.9 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-RF1	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	26.5 mm	62.5 mm	2.46 "	2.31 in	1.04 in	58.7 mm	84 %	Isolated Module	5 V
Cosel USA, Inc. CBS502405-RT	1	1.5 kV	OCP OVP Remote On/Off	18 V	ITE (Commercial)	Half Brick	36 V	-40 °C	100 °C	10 A	50 W	Through Hole	Half Brick	12.7 mm	61 mm	2.4 in	2.28 in	0.5 in	57.9 mm	84 %	Isolated Module	5 V
