ATS-02H Series

Manufacturer: Advanced Thermal Solutions Inc.

Catalog

Catalog

HEATSINK 60X60X25MM XCUT T766

...

Part	Thermal Resistance @ Forced Air Flow	Material	Fin Height	Fin Height	Package Cooled	Length [x]	Length [x]	Type	Width [y]	Width [y]	Attachment Method	Material Finish	Shape	Length	Length	Width [x]	Width [x]	Fin Height [custom]	Fin Height [custom]	Width	Width	Fin Height [z]	Fin Height [z]
Advanced Thermal Solutions Inc. ATS-02H-132-C2-R0	2.66 °C/W	Aluminum	25 mm	0.984 in	ASIC BGA CPU LGA	2.362 in	60 mm	Top Mount	2.362 in	60 mm	Push Pin	Blue Anodized	Fins Square
Advanced Thermal Solutions Inc. ATS-02H-204-C3-R0	7.54 °C/W	Aluminum	12 mm	0.472 in	ASIC BGA CPU LGA			Top Mount			Push Pin	Blue Anodized	Fins Square	2.126 in	54 mm	54 mm	2.126 in
Advanced Thermal Solutions Inc. ATS-02H-158-C1-R0	2.77 °C/W	Aluminum			ASIC BGA CPU LGA			Top Mount	1.575 in	40 mm	Push Pin	Blue Anodized	Fins Square					1.378 in	35 mm
Advanced Thermal Solutions Inc. ATS-02H-64-C3-R0	9.49 °C/W	Aluminum	25 mm	0.984 in	ASIC BGA CPU LGA			Top Mount	1.575 in	40 mm	Push Pin	Blue Anodized	Fins Square
Advanced Thermal Solutions Inc. ATS-02H-105-C1-R1	28.19 °C/W	Aluminum	9.5 mm	0.374 in	ASIC BGA CPU LGA	1.772 in	45 mm	Top Mount			Push Pin	Blue Anodized	Fins Square							1.772 in	45 mm
Advanced Thermal Solutions Inc. ATS-02H-62-C1-R0	16.45 °C/W	Aluminum			ASIC BGA CPU LGA			Top Mount	1.575 in	40 mm	Push Pin	Blue Anodized	Fins Square									15 mm	0.59 in
Advanced Thermal Solutions Inc. ATS-02H-130-C1-R0	5.21 °C/W	Aluminum			ASIC BGA CPU LGA	2.362 in	60 mm	Top Mount	2.362 in	60 mm	Push Pin	Blue Anodized	Fins Square									15 mm	0.59 in
Advanced Thermal Solutions Inc. ATS-02H-164-C1-R0	2.39 °C/W	Aluminum			ASIC BGA CPU LGA	1.772 in	45 mm	Top Mount			Push Pin	Blue Anodized	Fins Square					1.378 in	35 mm	1.772 in	45 mm
Advanced Thermal Solutions Inc. ATS-02H-30-C1-R0	5.3 °C/W	Aluminum	25 mm	0.984 in	ASIC BGA CPU LGA	2.756 in	70 mm	Top Mount			Push Pin	Blue Anodized	Fins Square			70 mm	2.756 "
Advanced Thermal Solutions Inc. ATS-02H-66-C2-R0	5.77 °C/W	Aluminum			ASIC BGA CPU LGA			Top Mount	1.575 in	40 mm	Push Pin	Blue Anodized	Fins Square					1.378 in	35 mm
