WTS26P Series
Manufacturer: SICK, Inc.
Beta
⌘K
SENSOR PROXIMITY 1.2M NPN/PNP
| Part | Adjustment Type | Ingress Protection | Sensing Method | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Light Source Wavelength (Red) | Light Source | Response Time | Operating Temperature (Max) | Operating Temperature (Min) | Connection Method | Output Configuration | Sensing Distance Maximum | Sensing Distance Minimum | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SICK, Inc. | Adjustable | IP66 IP67 | Proximity | 10 VDC | 30 VDC | 635 nm | Red | 1.25 ms | 60 °C | -40 °C | Connector M12 | NPN PNP Push-Pull | 47.24 " | 0.39 " | |
 SICK, Inc. | Adjustable | IP66 IP67 IP69K | Background Suppression Proximity | 10 VDC | 30 VDC | 635 nm | Red Red LED | 1.25 ms 1.4 ms | 60 °C | -40 °C | Connector M12 | NPN PNP Push-Pull | 39.37 " 47.24 " | 0.39 " | |
SICK, Inc. | Adjustable | IP66 IP67 | Proximity | 10 VDC | 30 VDC | 635 nm | Red | 1.25 ms | 60 °C | -40 °C | Cable with Connector | NPN PNP Push-Pull | 47.24 " | 0.39 " | 10.63 in |
SICK, Inc. | Adjustable | IP66 IP67 | Proximity | 10 VDC | 30 VDC | 635 nm | Red | 1.25 ms | 60 °C | -40 °C | Connector M12 | NPN PNP Push-Pull | 47.24 " | 0.39 " |
