BU27TD2WNVX Series
Manufacturer: Rohm Semiconductor
Beta
⌘K
200MA 2.7V, FIXED OUTPUT, HIGH PSRR, HIGH-ACCURACY CMOS LDO REGULATOR
| Part | Voltage - Input (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Mounting Type | Current - Output | Output Configuration | Number of Regulators | Current - Quiescent (Iq) | Protection Features | PSRR | Control Features | Voltage - Output (Min/Fixed) | Voltage Dropout (Max) | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 6 V | 85 °C | -40 C | 4-UDFN Exposed Pad | Surface Mount | 0.2 A | Positive | 1 | 60 µA | Over Current Over Temperature | 70 db | Enable | 2.7 V | 0.5 V | SSON004X1010 |
