60V 24A, Dual Nch+Nch, HSOP8, Power MOSFET
Description
AI
HP8KC7 is a low on-resistance MOSFET ideal for switching applications.
Beta
⌘K
60V 24A, Dual Nch+Nch, HSOP8, Power MOSFET
60V 24A, Dual Nch+Nch, HSOP8, Power MOSFET
| Part | Input Capacitance (Ciss) (Max) @ Vds [Max] | Operating Temperature | Current - Continuous Drain (Id) @ 25°C | Drain to Source Voltage (Vdss) | Mounting Type | Package / Case | Vgs(th) (Max) @ Id | Configuration | Gate Charge (Qg) (Max) @ Vgs | Supplier Device Package | Rds On (Max) @ Id, Vgs | Power - Max | Technology |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 1400 pF | 150 °C | 13.5 A 24 A | 60 V | Surface Mount | 8-PowerTDFN | 2.5 V | 2 N-Channel (Dual) | 22 nC | 8-HSOP | 11.5 mOhm | 3 W 26 W | MOSFET (Metal Oxide) |
