78ST1 Series
Manufacturer: Texas Instruments
Beta
⌘K
DC DC CONVERTER 6.5V
| Part | Mounting Type | Number of Outputs | Voltage - Input (Min) [Min] | Applications | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input (Max) [Max] | Current - Output (Max) [Max] | Type | Voltage - Output 1 | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Features | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Through Hole Right Angle | 1 | 7 V | ITE (Commercial) | 3-SIP Module | 85 °C | -40 °C | 30 V | 1.5 A | Non-Isolated PoL Module | 6.5 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | OTP SCP | |
 Texas Instruments | Surface Mount | 1 | 14.5 V | ITE (Commercial) | 3-SMD Module | 85 °C | -40 °C | 30 V | 1.5 A | Non-Isolated PoL Module | 12 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | OTP SCP | 90 % |
Texas Instruments | Through Hole Right Angle | 1 | 7 V | ITE (Commercial) | 3-SIP Module | 85 °C | -40 °C | 26 V | 1.5 A | Non-Isolated PoL Module | 3.3 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | OTP SCP | 80 % |
Texas Instruments | Through Hole Right Angle | 1 | 14.5 V | ITE (Commercial) | 3-SIP Module | 85 °C | -40 °C | 30 V | 1.5 A | Non-Isolated PoL Module | 12 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | OTP SCP | 90 % |
 Texas Instruments | Through Hole | 1 | 14.5 V | ITE (Commercial) | 3-SIP Module | 85 °C | -40 °C | 30 V | 1.5 A | Non-Isolated PoL Module | 12 V | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | OTP SCP | 90 % |
Texas Instruments | Through Hole | 1 | 7 V | ITE (Commercial) | 3-SIP Module | 85 °C | -40 °C | 30 V | 1.5 A | Non-Isolated PoL Module | 6.5 V | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | OTP SCP | |
Texas Instruments | Through Hole | 1 | 7 V | ITE (Commercial) | 3-SIP Module | 85 °C | -40 °C | 30 V | 1.5 A | Non-Isolated PoL Module | 5 V | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | OTP SCP | 85 % |
Texas Instruments | Through Hole | 1 | 14.5 V | ITE (Commercial) | 3-SIP Module | 85 °C | -40 °C | 30 V | 1.5 A | Non-Isolated PoL Module | 12 V | OTP SCP | 90 % | ||||||
 Texas Instruments | Surface Mount | 1 | 7 V | ITE (Commercial) | 3-SMD Module | 85 °C | -40 °C | 26 V | 1.5 A | Non-Isolated PoL Module | 3.3 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | OTP SCP | 80 % |
Texas Instruments | Surface Mount | 1 | 7 V | ITE (Commercial) | 3-SMD Module | 85 °C | -40 °C | 30 V | 1.5 A | Non-Isolated PoL Module | 6.5 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | OTP SCP |
