Super-Safeway Connector with Locking Blade, 3 Pole/3 Wire, Non-NEMA, 125V/250V Grounding Tab, Cord Grip Body Size F3
Super-Safeway Connector with Locking Blade, 3 Pole/3 Wire, Non-NEMA, 125V/250V Grounding Tab, Cord Grip Body Size F3
Super-Safeway Connector with Locking Blade, 3 Pole/3 Wire, Non-NEMA, 125V/250V Grounding Tab, Cord Grip Body Size F3
| Part | Features | Connector Type | Mounting Type | Current Rating (Amps) | Approval Agency | Termination | Connector Style | Voltage Rating | Voltage Rating | Number of Positions | Voltage Rating [Min] | Voltage Rating [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Cord-Clamp Strain Relief Locking Blade | Plug Male Blades | Free Hanging (In-Line) | 20 A | CSA UL | Screw | NEMA L21-20P | 208 VAC | 3 Phase | |||
 Molex | Cord-Clamp Strain Relief Locking Blade | Plug Male Blades | Free Hanging (In-Line) | 30 A | CSA UL | Screw | NEMA L17-30P | 600 VAC | 3 Phase | 4 | ||
 Molex | Cord-Clamp Strain Relief Locking Blade | Receptacle Female Sockets | Free Hanging (In-Line) | 20 A | CSA UL | Screw | NEMA L15-20R | 250 VAC | 3 Phase | 4 | ||
 Molex | Cord-Clamp Strain Relief Locking Blade | Plug Male Blades | Free Hanging (In-Line) | 30 A | CSA UL | Screw | NEMA L5-30P | 125 VDC | ||||
 Molex | Cord-Clamp Strain Relief Locking Blade | Plug Male Blades | Free Hanging (In-Line) | 30 A | CSA UL | Screw | NON-NEMA (3P3W) | 250 VAC | ||||
Molex | Locking Blade | Plug Male Blades | Free Hanging (In-Line) | 20 A | CSA UL | Screw | 4 | 125 VAC | 250 VAC | |||
Molex | Cord-Clamp Strain Relief Locking Blade | Plug Male Blades | Free Hanging (In-Line) | 20 A | CSA UL | Screw | NEMA L22-20P | 480 VAC | 3 Phase | |||
 Molex | Cord-Clamp Strain Relief Locking Blade | Receptacle Female Sockets | Free Hanging (In-Line) | 30 A | CSA UL | Screw | NEMA L15-30R | 250 VAC | 3 Phase | 4 | ||
 Molex | Cord-Clamp Strain Relief Locking Blade | Receptacle Female Sockets | Free Hanging (In-Line) | 20 A | CSA UL | Screw | NON-NEMA (4P4W) | 208 VAC | 4 | |||
 Molex | Cord-Clamp Strain Relief Locking Blade | Plug Male Blades | Free Hanging (In-Line) | 30 A | CSA UL | Screw | NEMA L22-30P | 480 VAC | 3 Phase |
