ZFKDSA Series
Manufacturer: Phoenix Contact
Beta
⌘K
FIXED TERMINAL BLOCKS 1P 10MM 135DEG END
| Part | Housing Material | Wire Termination | Color | Positions Per Level | Voltage | Current | Wire Gauge [Max] | Wire Gauge [Min] | Mounting Type | Mating Orientation | Mating Orientation | Number of Levels | Features | Pitch | Pitch | Positions Per Level [custom] | Mating Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | Green | 1 | 300 VDC | 30 A | 24 AWG | 10 AWG | Through Hole | 135 ° | 45 ° | 1 | |||||
 Phoenix Contact | Screwless - Spring Cage Tension Clamp | Green | 1 | 300 VDC | 10 A | 26 AWG | 12 AWG | Through Hole | 135 ° | 45 ° | 1 | ||||||
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | Green | 1 | 300 VDC | 10 A | 26 AWG | 16 AWG | Through Hole | 135 ° | 45 ° | 1 | Interlocking (Side) | ||||
 Phoenix Contact | Screwless - Spring Cage Tension Clamp | 4 | 300 VDC | 10 A | 26 AWG | 12 AWG | Through Hole | 135 ° | 45 ° | 1 | Interlocking (Side) | 0.197 in | 5 mm | ||||
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 300 VDC | 10 A | 26 AWG | 12 AWG | Through Hole | 135 ° | 45 ° | 1 | Interlocking (Side) | 0.197 in | 5 mm | 7 | |||
 Phoenix Contact | Screwless - Spring Cage Tension Clamp | Green | 10 | 300 VDC | 10 A | 26 AWG | 16 AWG | Through Hole | 1 | 0.15 in | 3.81 mm | Vertical with Board | |||||
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 32 | 24 AWG | 12 AWG | Through Hole | 135 ° | 45 ° | 1 | 0.2 in | 5.08 mm | ||||||
 Phoenix Contact | Screwless - Spring Cage Tension Clamp | Green | 3 | 16 A | Through Hole | 135 ° | 45 ° | 1 | Interlocking (Side) Lever Actuated | 0.2 in | 5.08 mm | ||||||
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | Yellow | 1 | 300 VDC | 10 A | 26 AWG | 12 AWG | Through Hole | 135 ° | 45 ° | 1 | Interlocking (Side) | ||||
 Phoenix Contact | Screwless - Spring Cage Tension Clamp | Green | 1 | 300 VDC | 10 A | 26 AWG | 16 AWG | Through Hole | 1 | Interlocking (Side) | Horizontal with Board |
