0447002 Series
350V MINI T HOLE EBF PB-FREE 2A GRAY
Manufacturer: Littelfuse/Commercial Vehicle Products
Catalog
350V MINI T HOLE EBF PB-FREE 2A GRAY
Beta
⌘K
350V MINI T HOLE EBF PB-FREE 2A GRAY
350V MINI T HOLE EBF PB-FREE 2A GRAY
350V MINI T HOLE EBF PB-FREE 2A GRAY
| Part | Voltage Rating - DC | Mounting Type | Package / Case | Melting I²t | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Voltage Rating - AC | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Fuse Type | Breaking Capacity @ Rated Voltage | Response Time | DC Cold Resistance | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Littelfuse/Commercial Vehicle Products | 125 VDC | Through Hole | Radial Box | 2.8 | 3.81 mm | 0.404 " | 0.43 " | 10.92 mm | 0.15 " | 10.26 mm | 350 V | 2 A | 125 °C | -40 °C | Board Mount | 50 A 100 A | Fast Blow | 0.056 Ohms | CSA METI UL |
 Littelfuse/Commercial Vehicle Products | 125 VDC | Through Hole | Radial Box | 2.8 | 3.81 mm | 0.404 " | 0.43 " | 10.92 mm | 0.15 " | 10.26 mm | 350 V | 2 A | 125 °C | -40 °C | Board Mount | 50 A 100 A | Fast Blow | 0.056 Ohms | CSA METI UL |
