21_N-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
21_N-50-12-60/033_-E
| Part | Body Material | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Body Finish | Dielectric Material | Mating Cycles | Center Contact Plating | Fastening Type | Number of Ports | Mounting Type | Contact Termination | Cable Group | Connector Type | Connector Style | Impedance | Center Contact Material | Shield Termination | Frequency - Max [Max] | Housing Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | Brass | -55 C | 85 °C | 1000 VDC | White Bronze | Polytetrafluoroethylene (PTFE) | 500 | Silver | Threaded | 1 | Free Hanging (In-Line) | Crimp | 1/2" Helical | Female Socket Jack | N Type | 50 Ohms | Bronze | Clamp | 11 GHz | Silver |
 Huber+Suhner, Inc. | Brass | -65 ░C | 165 °C | 1000 VDC | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 500 | Gold | Threaded | 1 | Free Hanging (In-Line) | Crimp | RG-400 | Female Socket Jack | N Type | 50 Ohms | Beryllium Copper | Crimp | 11 GHz | Silver |
 Huber+Suhner, Inc. | Brass | -65 ░C | 165 °C | 1000 VDC | White Bronze | Polytetrafluoroethylene (PTFE) | 500 | Gold | Threaded | 1 | Free Hanging (In-Line) | Crimp | LMR-195 | Female Socket Jack | N Type | 50 Ohms | Beryllium Copper | Crimp | 11 GHz | Silver |
 Huber+Suhner, Inc. | Brass | -40 C | 85 °C | 1000 VDC | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 500 | Silver | Threaded | 1 | Free Hanging (In-Line) | Crimp | 1/2" Helical | Female Socket Jack | N Type | 50 Ohms | Bronze | Clamp | 11 GHz | Silver |
 Huber+Suhner, Inc. | Brass | -60 °C | 165 °C | 1000 VDC | Nickel | Polytetrafluoroethylene (PTFE) | 500 | Gold | Threaded | 1 | Free Hanging (In-Line) | Crimp | Female Socket Jack | N Type | 50 Ohms | Beryllium Copper | Clamp | 18 GHz | Silver | |
 Huber+Suhner, Inc. | Brass | -40 C | 85 °C | 1000 VDC | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 500 | Silver | Threaded | 1 | Free Hanging (In-Line) | Crimp | Female Socket Jack | N Type | 50 Ohms | Bronze | Clamp | 11 GHz | Silver | |
 Huber+Suhner, Inc. | Brass | -65 ░C | 165 °C | 1000 VDC | White Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 500 | Gold | Threaded | 1 | Free Hanging (In-Line) | Crimp | Female Socket Jack | N Type | 50 Ohms | Beryllium Copper | Crimp | 11 GHz | Silver | |
 Huber+Suhner, Inc. | Brass | -65 ░C | 165 °C | 1000 VDC | White Bronze | Polytetrafluoroethylene (PTFE) | 500 | Gold | Threaded | 1 | Free Hanging (In-Line) | Crimp | LMR-400 | Female Socket Jack | N Type | 50 Ohms | Bronze | Crimp | 11 GHz | Silver |
 Huber+Suhner, Inc. | Brass | -65 ░C | 165 °C | 1000 VDC | White Bronze | Polytetrafluoroethylene (PTFE) | 500 | Silver | Threaded | 1 | Free Hanging (In-Line) | Crimp | LMR-500 | Female Socket Jack | N Type | 50 Ohms | Bronze | Crimp | 6000 MHz | Silver |
Huber+Suhner, Inc. | Brass | -65 ░C | 165 °C | 1000 VDC | White Bronze | Polytetrafluoroethylene (PTFE) | 500 | Silver | Threaded | 1 | Free Hanging (In-Line) | Crimp | RG-141 | Female Socket Jack | N Type | 50 Ohms | Beryllium Copper | Clamp | 6000 MHz | Silver |
