807-036 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 72POS 0.156
...
| Part | Contact Type | Read Out | Number of Rows | Pitch [x] | Pitch [x] | Flange Feature | Mounting Type | Number of Positions/Bay/Row [custom] | Contact Finish | Card Type | Termination Rows | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Termination | Contact Material | Material - Insulation | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Gender | Color | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Semi Bellows | Dual | 2 | 0.156 in | 3.96 mm | Flush Mount M3 Threaded Insert Top Opening | Through Hole | 36 | Tin | Non Specified - Dual Edge | 1 | 125 °C | -40 °C | 72 | Solder Eyelet(s) | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | |||||||
 EDAC Inc. | Semi Bellows | Dual | 2 | 0.156 in | 3.96 mm | Through Hole | 36 | Tin | Non Specified - Dual Edge | 1 | 125 °C | -40 °C | 72 | Solder Eyelet(s) | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | ||||||||
 EDAC Inc. | Semi Bellows | Single | 1 | 0.156 in | 3.96 mm | Flush Mount Top Opening Unthreaded | Through Hole | 36 | Gold | Non Specified - Single Edge | 1 | 125 °C | -40 °C | 36 | Solder | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | 3.25 mm | 0.128 " | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Semi Bellows | Single | 2 | 0.156 in | 3.96 mm | Flush Mount M3 Threaded Insert Top Opening | Through Hole Right Angle | 18 | Gold | Non Specified - Dual Edge | 2 | 125 °C | -40 °C | 36 | Solder | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | 10 Áin | 0.25 Ám | |||||
 EDAC Inc. | Semi Bellows | Dual | 2 | 0.156 in | 3.96 mm | Through Hole | 18 | Tin | Non Specified - Dual Edge | 2 | 125 °C | -40 °C | 36 | Solder | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | ||||||||
 EDAC Inc. | Semi Bellows | Single | 2 | 0.156 in | 3.96 mm | Side Mount Opening Unthreaded | Through Hole Right Angle | 18 | Tin | Non Specified - Dual Edge | 2 | 125 °C | -40 °C | 36 | Solder | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | 3.25 mm | 0.128 in | |||||
 EDAC Inc. | Semi Bellows | Dual | 2 | 0.156 in | 3.96 mm | Side Mount Opening Unthreaded | Through Hole | 18 | Tin | Non Specified - Dual Edge | 2 | 125 °C | -40 °C | 36 | Solder | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | 3.25 mm | 0.128 in | |||||
 EDAC Inc. | Semi Bellows | Dual | 2 | 0.156 in | 3.96 mm | Flush Mount Top Opening Unthreaded | Board Edge Straddle Mount | 18 | Gold | Non Specified - Dual Edge | 2 | 125 °C | -40 °C | 36 | Solder | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | 3.96 mm | 0.156 in | 10 Áin | 0.25 Ám | Card Extender | ||
 EDAC Inc. | Semi Bellows | Dual | 2 | 0.156 in | 3.96 mm | Flush Mount Top Opening Unthreaded | Through Hole | 36 | Gold | Non Specified - Dual Edge | 1 | 125 °C | -40 °C | 72 | Wire Wrap | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | 3.25 mm | 0.128 " | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Semi Bellows | Single | 1 | 0.156 in | 3.96 mm | Side Mount Opening Unthreaded | Through Hole Right Angle | 36 | Tin | Non Specified - Single Edge | 1 | 125 °C | -40 °C | 36 | Solder | Copper Alloy | Diallyl Phthalate (DAP) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | Green | 3.25 mm | 0.128 in |
