MAX544 Series

Catalog

IC DAC 14BIT V-OUT 8SOIC

Part	INL/DNL (LSB)	Number of Bits	Settling Time	Mounting Type	Package / Case	Package / Case [y]	Package / Case [x]	Supplier Device Package	Voltage - Supply, Digital	Voltage - Supply, Analog	Architecture	Reference Type	Data Interface	Output Type	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case
Analog Devices Inc./Maxim Integrated MAX544ACSA	0.15 LSB	14	1 µs	Surface Mount	8-SOIC	3.9 mm	0.154 in	8-SOIC	5 V	5 V	R-2R	External	SPI	Voltage - Unbuffered	70 °C	0 °C
Analog Devices Inc./Maxim Integrated MAX544BESA	0.15 LSB	14	1 µs	Surface Mount	8-SOIC	3.9 mm	0.154 in	8-SOIC	5 V	5 V	R-2R	External	SPI	Voltage - Unbuffered	85 °C	-40 °C
Analog Devices Inc./Maxim Integrated MAX544BCSA+	0.15 LSB	14	1 µs	Surface Mount	8-SOIC	3.9 mm	0.154 in	8-SOIC	5 V	5 V	R-2R	External	SPI	Voltage - Unbuffered	70 °C	0 °C
Analog Devices Inc./Maxim Integrated MAX544BCPA+	0.15 LSB	14	1 µs	Through Hole	8-DIP			8-PDIP	5 V	5 V	R-2R	External	SPI	Voltage - Unbuffered	70 °C	0 °C	0.3 in	7.62 mm
Analog Devices Inc./Maxim Integrated MAX544AESA+	0.15 LSB	14	1 µs	Surface Mount	8-SOIC	3.9 mm	0.154 in	8-SOIC	5 V	5 V	R-2R	External	SPI	Voltage - Unbuffered	85 °C	-40 °C
Analog Devices Inc./Maxim Integrated MAX544AESA	0.15 LSB	14	1 µs	Surface Mount	8-SOIC	3.9 mm	0.154 in	8-SOIC	5 V	5 V	R-2R	External	SPI	Voltage - Unbuffered	85 °C	-40 °C
Analog Devices Inc./Maxim Integrated MAX544ACSA+	0.15 LSB	14	1 µs	Surface Mount	8-SOIC	3.9 mm	0.154 in	8-SOIC	5 V	5 V	R-2R	External	SPI	Voltage - Unbuffered	70 °C	0 °C
