4605M Series
Manufacturer: Bourns Inc.
Beta
⌘K
CAP ARRAY 10000PF 50V X7R 5SIP
| Part | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Package / Case | Temperature Coefficient | Capacitance | Number of Capacitors | Voltage - Rated | Mounting Type | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Tolerance | Circuit Type | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Temperature Coefficient | Number of Resistors | Resistor-Ratio-Drift | Operating Temperature [Min] | Operating Temperature [Max] | Supplier Device Package | Resistance (Ohms) | Number of Pins | Power Per Element | Resistance (Ohms) [custom] | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 5.08 mm | 0.2 in | 5-SIP | X7R | 10000 pF | 4 | 50 VDC | Through Hole | 12.7 mm | 0.15 " | 0.5 " | 3.81 mm | 20 % | Bussed | |||||||||||||
 Bourns Inc. | 5-SIP | Through Hole | 12.65 mm | 0.098 in | 0.498 " | 2.49 mm | 2 % | Bussed | 6.35 mm | 0.25 in | 100 ppm/°C | 4 | 50 ppm/°C | -55 C | 125 °C | 5-SIP | 120 Ohms | 5 | 250 mW | ||||||||
Bourns Inc. | 5-SIP | Through Hole | 12.65 mm | 0.098 in | 0.498 " | 2.49 mm | 2 % | Bussed | 6.35 mm | 0.25 in | 100 ppm/°C | 4 | 50 ppm/°C | -55 C | 125 °C | 5-SIP | 5 | 250 mW | 820 Ohms | ||||||||
Bourns Inc. | 5.08 mm | 0.2 in | 5-SIP | X7R | 100000 pF | 4 | 50 VDC | Through Hole | 12.7 mm | 0.15 " | 0.5 " | 3.81 mm | 20 % | Bussed | |||||||||||||
Bourns Inc. | 5-SIP | Through Hole | 12.65 mm | 0.098 in | 0.498 " | 2.49 mm | 2 % | Bussed | 6.35 mm | 0.25 in | 100 ppm/°C | 4 | 50 ppm/°C | -55 C | 125 °C | 5-SIP | 5 | 250 mW | 1k |
