090121 Series

Manufacturer: Molex

Catalog

CONN HEADER R/A 20POS 2.54MM

Part	Material Flammability Rating	Number of Positions Loaded	Applications	Termination	Number of Positions	Contact Type	Number of Rows	Pitch - Mating	Pitch - Mating	Fastening Type	Insulation Color	Contact Finish - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Height	Insulation Height	Contact Length - Post	Contact Length - Post	Insulation Material	Contact Shape	Contact Material	Connector Type	Style	Contact Length - Mating	Contact Length - Mating	Shrouding	Mounting Type	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)	Mated Stacking Heights	Voltage Rating
Molex 0901210140	UL94 V-0	All	Automotive General Purpose	Solder	20	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	118.1 µin	3 µm	3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle
Molex 0901210766	UL94 V-0	All	Automotive General Purpose	Solder	6	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	0.38 µm		3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle	Gold	15 µin	3 µm	118.1 µin
Molex 0901210134	UL94 V-0	All	Automotive General Purpose	Solder	14	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	118.1 µin	3 µm	3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle
Molex 0901211117	UL94 V-0	All	General Purpose	Solder	37	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Gold					0.114 in	2.9 mm	Polyester	Square	Brass	Header	Board to Cable/Wire			Unshrouded	Through Hole Right Angle	Gold		1 çm	39.4 çin	-55 °C	125 °C	3 A	5 mm	350 V
Molex 0901210924	UL94 V-0	All	Automotive General Purpose	Solder	4	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	0.76 Ám		3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle	Gold	30 Áin	3 µm	118.1 µin
Molex 0901210956	UL94 V-0	All	Automotive General Purpose	Solder	36	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	0.76 Ám		3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle	Gold	30 Áin	3 µm	118.1 µin
Molex 0901210126	UL94 V-0	All	Automotive General Purpose	Solder	6	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	118.1 µin	3 µm	3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle
Molex 0901210928	UL94 V-0	All	Automotive General Purpose	Solder	8	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	0.76 Ám		3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle	Gold	30 Áin	3 µm	118.1 µin
Molex 0901210775	UL94 V-0	All	Automotive General Purpose	Solder	15	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	0.38 µm		3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle	Gold	15 µin	3 µm	118.1 µin
Molex 0901210764	UL94 V-0	All	Automotive General Purpose	Solder	4	Male Pin	1	0.1 in	2.54 mm	Push-Pull	Black	Tin	0.38 µm		3.6 mm	0.142 in	0.114 in	2.9 mm	Polyester Glass Filled	Square	Brass	Breakaway Header	Board to Board Cable	0.266 in	6.75 mm	Unshrouded	Through Hole Right Angle	Gold	15 µin	3 µm	118.1 µin
